PCB Plug-in Terminal Block Pin Header
Negotiable
MOQ: 500 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SCED
Model Number:
TP508H-00F
Payment & Shipping
Payment Methods:
Port of Shipment:
Yantian Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Plug in Terminal Block Female PartsNegotiableMOQ: 500 Pieces -
3.5mm Pitch Male and Female Terminal Block Pluggable Terminal BlockNegotiableMOQ: 500 Pieces
-
Male and Female Terminal Block Pluggable and Plug-in Terminal BlockNegotiableMOQ: 500 Pieces
-
Pluggable Terminal Block 3.81mm Male Terminal BlockNegotiableMOQ: 500 Pieces
-
Double Row Pin Header Pluggable Terminal BlockNegotiableMOQ: 500 Pieces
Place of Origin
Guangdong, China
Brand Name
SCED
Model Number
TP508H-00F
Number of Contacts
1 - 10
Conductor Size
11 - 20 AWG
Type
Plug-in
Parameter and Drawing Specifications:
UL Technical Data |
B |
C |
D |
Rated Voltage / Current V/A |
300/18 |
|
300/18 |
IEC Technical Data |
|
||
Overvoltage Category |
Ⅲ |
Ⅲ |
Ⅱ |
Contamination Class |
3 |
2 |
2 |
Rated Voltage / Current V/A |
250 / 18 |
400 / 18 |
500 / 18 |
Rated Surge Voltage KV |
4 |
4 |
4 |
Material |
|
||
Insulation Material / Inflammability Class |
PA66 / UL94, V-0 |
||
Terminal / Plating |
Brass / Tin Plated |
||
Other Data |
|
||
PCB Hole Diameter mm |
φ1.4 |
||
Pin Dimension mm |
1.0 x 1.0 |
||
This male header match with female plugs’ series: TP508P-00F, TP508P-02F, TP508P-03F, TP508P-04F, TP508P-05F, TP508P-07F
Standard color: Green. Other colors also available, please refer to below How to Order and select the color you want.
How to order:
Send Inquiry to This Supplier
* Email
Want the best price?
Post an RFQ now!
Business Type
Manufacturer
Year Established
2005
Factory Size
10,000-30,000 square meters
Total Employees
501 - 1000 People
