Specifications
1.High tempreature and high pressure resistant2.Longevity,healthy&recyclable
3.Easy to install
4.ISO,BV
COMPANY INFORMATION:
Junxing Pipe Group Co.,Ltd is located in Fuyuan Economic Development Area, Tianjin City, covering an area of 150,000 square meters. We manufacture PP-R, PB, HDPE, PE-RT, PE-Xa, PE-Xb, DXPAP1, DXPAP2, DXPAP5, RDPAP7 pipes and fittings, which are used in areas such as water transportation, gas transportation and geotherm industry etc.
Our company has passed the certificates of GOST, BV, ISO9001 and ISO14001, certificates of China Environmental Label Products and China Water Saving Products. Strategic objectives: constant pursuits, innovative development, being based on domestic needs and expanding to the world.
PRODUCT INFORMATION
Product Name: |
Butt welding Aluminum-plastic composite pipe RPAP5 |
Brand: |
Junxing |
dn: |
16mm-32mm |
Wall Thickness/Dimension: |
2.3mm to 3.0mm |
Classify rate to thickness: |
2.3mm to 3.0mm |
Nominal Pressure: |
1.25Mpa,1.6Mpa |
Material: |
Pert |
Color: |
White or customized |
Length: |
4m of straight, coil or as requested |
Packing: |
In coils or 4m/piece by plastic bag |
Connection: |
electro-fusion |
Standard: |
CJ/T 159-2006 |
Service Life: |
Minium 50 years life under normal condition |
Application: |
Cold and hot water distribution,gas and air |
|
More Detail:
| |
Produce capacity: |
160,000tons/year |
Minium order quantity: |
500m |
Origin: |
Tianjin City, China |
Delivery: |
Within 10-15 days after the firm order date |
Payment Method: |
T/T, L/C,D/P, etc |
Trade Term: |
FOBTianjin, CIF, CFR,etc |
Sample: |
Free sample available for your quality test
|
Other: |
OEM accept |
RPAP5 pipe/PERT-aluminum composite pipe
Details:
- Material:PE-RT and aluminum composite
- Sizes: dn16mm to 32mm
- Working tempreature: 95 degree
- Colors:white or other colors on request
- Connection: butt welding
- Standard: CJ/T159-2006
- Factory Certification: ISO9001, ISO14001, BV
- Product Certification: CE Certification,BV(Bureau Veritas)Certificate
- Applications: Cold or hot water supply, heating system including flooring heating, wall heating and radiating system, Central air conditioning system, industrial liquids transportation
RPAP5
1, Non-toxic, corrosion resistance,light weight, good mechanical strength and more heat-resisting performance, long service life.
2, Fluid resistance inside pipe is small, not easy scaling, fluid not being polluted, and effective large diameter.
3, 100% insulating oxygen,stop oxygen's penetration. Aluminum-plastic pipes can be used as floor heating, shielding of communications lines, and prevent various audio, magnetic interference; Because of their good antistatic performance, they are also suitable for conveying gas and fuel. Pipes can be bent freely and made straight back
RPAP5
| Nominal outside diameter | Thickness of pip wall | Thickness of internal plastic wall | Minimal thickness of external plastic wall | Thickness of Aluminum wall |
| 20 | 2.5 | 1.5 | 0.3 | 0.36 |
| 25 | 3.0 | 1.7 | 0.3 | 0.44 |
| 32 | 3.0 | 1.6 | 0.3 | 0.60 |
cold water pip hot water pipe
| Outside diameter | Inside diameter | Outside diameter | Inside diameter |
| 16 | 12 | 16 | 12 |
| 20 | 16 | 12 | 16 |
| 25 | 20 | 25 | 20 |
| 32 | 26 | 32 | 26 |
| 40 | 32 | 40 | 32 |
| 50 | 40 | 50 | 40 |
fittings
Application:
1.Floor heating system pip
2.Hot and cold potable water systems
2.Drink water system
3.Solar facilities systems
6.Rain water and swimming pool pipe network system
Advantage:
(1)high quality
(2)work pressure :1.25MP
(3)Burst pressure:dn207Mpa, dn256Mpa, dn325Mpa
(4) Standard: ISO9001-2000
(5)pe-rt fitting(female tee )
(6)Pe-rt fitting( male tee)
CERTIFICATES:
Frequently asked questions?
Q:What material are you specialized in?
A: We manufacture PP-R, PB, HDPE, PE-RT, PE-Xa, PEXb, DXPAP1, DXPAP2, DXPAP5, RDPAP7 pipes and fittings.
Q: The price of your products is higher than others.
A: We can't promise you the best price, but we can promise you the best quality. We import row material from famous companies such as LG Chemical, Iydellbasell, Chervrom, Sinopec.
Q: For pipe fittings, what do you do mainly?
A: For fittings, coupling, elbows, tee, reducer, valve and cap are our main products.
