prp pipe prp tube
We supply both ppr pipes and fittings.
* Sizes: 20mm to 200mm.
* Colour: green, white, grey or other colors as request.
* Material: Random Polypropylene (HYOSUNG R200P,Korea)
* Pressure Rating: 1.25MPa, 1.6MPa, 2.0MPa ,2.5MPa.
* Connection: socket fusion joint, electro fusion joint or transition joint
* Certificates: ISO9001, ISO14001, OHSAS18001,BV.CE, GOST, WATERMARK, WRAS etc.
Junxing manufactures PPR pipes for hot/cold water system installations. Our PPR pipes,made of the highest quality PPR materials,is tested under extreme conditions&conforms to globle quality standards. Conforming to world class standards of quality,they are extremely reliable&offer convenient&reliable installation in any plumbing system.
Applications: Cold or hot water supply, heating system including flooring heating, wall heating and radiating system, Central air conditioning system, industrial liquids transportation.Pipe for toilet-flushing,greening,landscaping,vehicle washing and floor cleaning.
Advantages:
1. High temperature resistance: the maximum sustained working temperature is up to 70 degrees, the maximum transient temperature is up to 95 degrees.
2. Heat preservation: low thermal conductivity result in preserving heat.
3. Non-toxic: no heavy metal additives, would not be covered with dirt or contaminated by bacterium
4. Lower installation costs: light weight and ease of installation can reduce installation costs
5. Higher flow capacity: smooth interior walls result in low pressure loss and high volume.
6. Corrosion resistant: resist chemical matters or electron chemical corrosion.
PPR pipe Specification:
| Pressure rating | Size | Pressure rating | Size | Pressure rating | Size | Pressure rating | Size |
|
S5,1.25Mpa PPR pipe for cold water |
20x2.0 |
S4, 1.6Mpa, PPR pipe for cold water |
20x2.3 |
S3.2, 2.0Mpa PPR pipe for hot water |
20x2.8 |
S2.5, 2.5Mpa PPR pipe for hot water |
20x3.4 |
| 25x2.5 | 25x2.8 | 25x3.5 | 25x4.2 | ||||
| 32x2.9 | 32x3.6 | 32x4.4 | 32x5.4 | ||||
| 40x3.7 | 40x4.5 | 40x5.5 | 40x6.7 | ||||
| 50x4.6 | 50x5.6 | 50x6.9 | 50x8.3 | ||||
| 63x5.8 | 63x7.1 | 63x8.6 | 63x10.5 | ||||
| 75x6.8 | 75x8.4 | 75x10.3 | 75x12.5 | ||||
| 90x8.2 | 90x10.1 | 90x12.3 | 90x15.0 | ||||
| 110x10.0 | 110x12.3 | 110x15.1 | 110x18.3 | ||||
| 125x11.4 | 125x14.0 | 125x17.1 | 125x20.8 | ||||
| 140x12.7 | 140x15.7 | 140x19.2 | 140x23.3 | ||||
| 160x14.6 | 160x17.9 | 160x21.9 | 160x26.6 | ||||
| 200x18.2 | 200x22.2 | 200x27.9 | 200x33.3 |
1. PE Pipes: PE water supply pipe, HDPE dredging pipe,PE Gas Pipe,PE Geothermal Pipe, PE-KM pipe for mines.
2. HDPE Double Wall Corrugated Pipe.
3. Pipes for floor heating: PB Pipe, PB/EVOH Pipe, PEX Pipe,PE-RT Pipe,PE-RT/EVOH Pipe.
4. Butt welding Aluminum-Plastic Composite Pipes: PERT-AL-PERT Pipe(RPAP5), PEX-AL-PET Pipe(DXPAP2),PERT-AL-PERT Pipe(RDPAP 7),PE-AL-PE Pipe.
5.PPR Pipes: PPR Hot/Cold Water Pipe, PPR-FB-PPR Pipe, PPR-AL-PPR Pipe,Nano Anti-bacterial PPR Pipe(βPPR).
6. Relative Pipe Fittings for above pipes: Tee/Valve/Elbow/Union/melt machines/bend/cross/coupling.
