Factory price composite pipe, polyethylene aluminum composite pipe
Pipe for gas pipeline system.
Pipes for hot and cold water pipeline system in industry and residentiak area.
Pipes for industry and chemical liquids conveying.
Pipes for conveying drinking water.
Pipeline for compressed air.
Heating system underfloor and wall.
Medium layer of aluminum plastic composite pipe is welded aluminum band, inner and external layers are all made of polyethylene. Special-purpose hot melting adhesive is used, and extrusion molding method is adopted for composite of pipe. Pressure resistance of metal pipe and corrosion resistance of plastic pipe are combined together on the pipe. The aluminum layer allows PE-AL-PE multi layer composite pipe to withstand high working pressure and prevent oxygen and gased from penetrating into the pipe. They are easily bent, which makes the use of numerous fittings unnecessary.
Specification of PE-AL-PE pipe:
| Product | Nominal Diameter (mm) | Inner Diameter (mm) | Thickness of aluminium layer (mm) | Length |
|
PE-AL-PE pipe; PEX-AL-PEX pipe; PERT-AL-PERT pipe; |
16 | 12 | 0.25 | 100~300Meters/roll |
| 20 | 16 | 0.3 | ||
| 25 | 20 | 0.35 | ||
| 32 | 32 | 0.5 |
Physical Performance of PE-AL-PE pipe:
| Item | Requirement |
coefficient of thermal conductivity, W/m.k |
0.45 |
| coefficient of thermal expansion, M/m.k | 2.5x10-5 |
| benging radius | ≥5D |
| working temperature | -40~+95 |
| working pressure | ≤1.25 |
| radial force | 2300~2650 |
| bursting strength | 4.0~6.0 |
1. The raw material for our PEX-AL-PEX pipe is LG XL6500 from South Korea.
2. The raw material for our PERT-AL-PERT pipe is LG SP980 from South Korea.
3. The raw material for our PE-AL-PE pipe is Borouge 3490.
