Help CenterBIDI XFP 1270nm&1330nm 10KM DDM CT
Related Products
-
Dual Fiber XFP DFB 1310nm&PIN 10KM DDM CTUS$ 50 - 60MOQ: 1 Unit -
BIDI XFP 1270nm&1330nm 10KM DDM CTUS$ 50 - 70MOQ: 1 Unit
-
XFP SR VCSEL 850nm&PIN Transceiver 300m 10Gbps LC CISCO/HUAWEI/HP Compatible Commercial Temperature FTTH Optical ModuleUS$ 25 - 40MOQ: 1 Unit
-
XFP LR DFB 1310nm&PIN Transceiver 10Km 10Gbps LC CISCO/HUAWEI/HP Compatible Commercial Temperature FTTH Optical ModuleUS$ 40 - 60MOQ: 1 Unit
-
XFP ER DFB 1550nm&PIN Transceiver 40Km 10Gbps LC CISCO/HUAWEI/HP Compatible Commercial Temperature FTTH Optical ModuleUS$ 180 - 210MOQ: 1 Unit
ZKTel's BID XFP transceivers are designed for bi-directional 10G serial optical data communications such as IEEE 802.3ae 10GBASE-BX by using 1330(1270)nm transmitter and 1270(1330) nm receiver. The transceiver consists of two sections: The transmitter section uses a multiple quantum well 1330(1270) nm DFB laser and is a class 1 laser compliant according to International Safety Standard IEC 60825. The receiver section uses an integrated 1270(1330) nm detector preamplifier (IDP) mounted in an optical header and a limiting post-amplifier IC.
Features: |
|
l One Fiber Bi-Directional XFP Optical Transceiver, Bidi XFP l Fully Compliant with XFP MSA l Compliant to IEEE 802.3ae 10GBASE-BX l SFF-8472 Digital Diagnostic Function l Simplex LC Connector l 1330TX/1270RX and 1270TX/1330RX l Distance Up to 10, 20, 40 km l XFI Loopback Mode l No reference Clock required l RoHS Compliant l -5 to 70oC Operating Temperature l Simplex LC Connector |
Application: |
|
l 10GBASE-BX at 10.3125 Gb/s l 10GBASE-BX at 9.953 Gb/s |
