Help CenterOptical Component TOSA 1.25Gbps Power Supply 3.3V TIA 4PIN
Related Products
-
1310nm DFB 10Gbps Optical Sub Assembly TOSA SFP 0.5~1.2mW With Isolator -40~85CUS$ 5 - 10MOQ: 1 Unit -
TOSA 1.25G Fiber Optical Component LC -40~85CUS$ 3 - 8MOQ: 1 Unit
-
TOSA 1.25G Optical Component LC -40~85US$ 3 - 8MOQ: 1 Unit
-
TOSA 1.25G Optical Component LC -40~85CUS$ 3 - 8MOQ: 1 Unit
-
TOSA 1.25G Optical Component LC -40~85CUS$ 3 - 8MOQ: 1 Unit
ZKTel offers lasers/TOSA for digital, analogue, CWDM and supervisory channel applications. Additionally we can supply Mini-TOSAs optimized for SFF and SFP designs and various FTTx devices.
Digital transmission
Economical un-cooled lasers for digital applications up to 2.5Gbps
InGaAsP/InP, SMQW lasers (Fabry-Perot and DFB) for low threshold current (typically 5-8mA)
Wide temperature operation from -40 to 85°C (95°C for some lasers)
Multiple package types available including TOCAN, transmission optical sub assemblies (TOSA), FC and SC receptacle, and pigtailed
Designed to meet Telcordia (Bellcore) and ITU-T requirements
Lasers for analogue applications
Lasers for CWDM applications
DWDM and supervisory channel lasers
Mini-TOSAs
FTTx devices
Main Features
Part No. Source Wavelength Data Rate Output Power Package series Connector Pin Type Isolation Fiber Type
ZT614-6xx1 DFB 1550nm 2.5G 2-3mw Receptacle F SC LD-Pin-1 Single Stage None
ZT412-5xx5 DFB 1310nm 1.25G 0.3-1mw Receptacle A FC-1 LD-Pin-2 None None
ZT513-5xx5 FP 1550nm 1.25G 1-2mw Receptacle B FC-2 LD-Pin-2 Single Stage None
ZT312-5xxx FP 1310nm 1.25G 0.3-1mw Receptacle E ST-1 LD-Pin-2 None None
ZT615-6xx7 DFB 1550nm 2.5G 3-4mw D FC/APC LD-Pin-1 Single Stage SM
ZT415-5xx9 DFB 1310nm 1.25G 2-3mw B SC/APC LD-Pin-1 Single Stage SM
ZT315-5xx7 FP 1310nm 1.25G 1-2mw A FC/APC LD-Pin-1 Single Stage SM
ZT515-5xx7 FP 1550nm 1.25G 1-2mw A FC/APC LD-Pin-1 Single Stage SM
ZT714-5xx7-29x CWDM DFB 1290nm 1.25G 2-3mw Pigtail B FC/APC LD-Pin-2 Single Stage SM
ZT714-5xx9-47x CWDM DFB 1470nm 1.25G 2-3mw Pigtail B SC/APC LD-Pin-1 Dual Stage SM
ZT714-5xx9-59x CWDM DFB 1590nm 1.25G 2-3mw Pigtail B SC/APC LD-Pin-1 Single Stage SM
ZT714-5xx9-61x CWDM DFB 1610nm 1.25G 2-3mw Pigtail B SC/APC LD-Pin-1 Dual Stage SM
ZT511-6xx3 FP 1550nm 2.5G 0.3-0.5mw Receptacle LC-TOSA LD-Pin-2 None None
ZT411-5xx3 DFB 1310nm 1.25G 0.3-0.5mw Receptacle LC-TOSA LD-Pin-1 Single Stage None
ZT613-6xx3 DFB 1550nm 2.5G 1-1.59mw Receptacle LC-TOSA LD-Pin-2 Single Stage None
ZT311-6xx3 FP 1310nm 2.5G 0.15-0.3mW Receptacle LC-TOSA LD-Pin-2 None None
ZT713-6xx9-61x DFB 1610nm CWDM 2.5G 1-1.59mw Receptacle LC-TOSA LD-Pin-2 Single Stage None
ZT312-10xx3 DFB 1310nm 10G 0.2-1mW Receptacle LC-TOSA LD-Pin-2 Single Stage None
ZT312-5xx1 DFB 1310nm 1.25G 0.5-1mW Receptacle SC-TOSA6 LD-Pin-2 None None
