GRADE:SB-PFT(Polyimide film tubing)
Operating temperature:-60°C~+220°C
STRUCTURE
Polyimide film tubin is manufactured by twisted polyimide film then adhesives by special glue. The glue
possesses similar chemical characteristics with polyester film.
USAGE
Main application range: insulation and mechanical protection for soldering, connection, wire harness,
transformer, motor, cable, heating element, capacitor, telephone, electrical appliance etc.
PRODUCT CHARACTERISTICS
Dimension |
Inside diameter2.0-65(mm),Thickness 0.05-1 (mm), Length10-1000(mm) |
|
Color |
light yellow |
|
Melting point |
250°C-265°C |
|
Service temperature |
-269~260°C |
|
Density |
1.42+/-0.02 |
|
Tensile strength |
Longitudinal >=130mpa; Horizontal>=110mpa |
|
Water absorption |
75% max after 24 hr immersion |
|
Corrosive on Copper |
Negligible |
|
Solubility in acid, oil, paint, industrial solvents tec. |
Undissolved |
|
Antibacterial, anti corrosive |
Excellent |
|
Tenacity |
Excellent |
|
Cuticle intensity |
≥35% |
|
Resistance pressure |
50HZ 115MV/min Not perforative |
|
Visual |
Smooth, No fleck & Eye winker |
|
Surface resistivity:(200°C) |
≥1.0x1013 |
|
Volume resistivity:(200°C) |
≥3.8x1010 |
|
Dielectric coefficient:(50HZ) |
3.5 |
|
Dielectric loss:(50HZ) |
≤4X10-3 |
|
Flammability |
Slow to self-extinguishing |
Burning resistance |
Resistance characteristics |
Resistance to abrasion, acids, immersion, mildew, industrial solvent, mechanical destroy, Freon and special liquids |
|
Xylene extraction |
<2% |
|
Environment protection |
No hurtful to human and environment |
|
Note: Besides above dimension, we can manufacture other dimension upon request.
Q : Are you a factory or trading company ?
A: We are a factory , can offer best quality product and reasonable price for you.
Q: Can you accept sample order?
A: Yes, we accept samples with little and reasonable charge.
Q: What is your MOQ?
A: Normally,1000 Meter per color.
Q:What is your delivery time?Can we short it in 7 days or less?
A: 3 days for sample, 3-25 days for mass production(depend quantity).
Q: What is your payment terms?
A: T/T,Western Union
Q: How can I get my order?
A: We will send you the goods by UPS, DHL, Fedex, Oversea Shipment or other forwarder, all with tracking number.
Q:How about your quality?
A: All of our products have obtained the UL and CSA certificates (Cert No:E333178--UZIQ2,VW-1&E333177--UZFT2/8 ,200C,600V).Try a small order, you will have your judgements!
