Specifications
Howo wrecker truck with platform4ton winch
platform dimension(L*W): 5.5*2.3m
new cabin
ISO, CCC quality approved
Howo wrecker truck with platform
Not only can transport severely damaged vehicles, but also have the capacity to grab another car on the ride to your lot using the independent wheel lift with swivel scoop pans.
Why choose this Howo wrecker truck with platform:
1. This car towing truck is retrofitted from Howo chassis, Howo is one of the largest vehicle manufacturer in China.
2. This car towing truck quality have been approved by ISO, China CCC, our factory have been in car towing truck line for years, the quality is high, price is reasonable.
3. This car towing truck could be loaded into container for ocean shipment.
Our service
1. Reply your question within 24hour.
2. one year of warranty since bill of lading on board date
3. provide english operation manual, english maintance manual
4. Free trainning in our factory if customer need.
Entire vehicle |
Type |
JDF5071TQZB4 |
|
Dimensions parameter |
Length(mm) |
7440 |
|
Wide(mm) |
2320 |
||
High(mm) |
2600 |
||
Wheelbase(mm) |
3800 |
||
Mass parameter |
GVW (kg) |
7140 |
|
Curb weight (kg) |
5945 |
||
Chassis |
Type |
BJ1073VCJFG-L1 |
|
Engine |
Type |
CY4102-C3C |
|
Power(kw) |
88 |
||
Size of tire |
7.50-16 |
||
Specialized device |
Flat organization |
Length x width (mm) |
5500x2300 |
Flat stroke (mm) |
3320 |
||
Flat minimum inclination angle (°) |
8 |
||
Flat maximum bearing quality (kg) |
3000 |
||
Rated traction winch (kg) |
4000 |
||
The length of wire rope (m) |
21 |
||
Lifting mechanism |
Effective length (mm) |
1300 |
|
Rated lifting quality (kg) |
2100 |
||
Full extend maximum lift quality (kg) |
1600 |
||
Rated supporting lead quality (kg) |
7140 |
||
Could option crane to be mounted on the wrecker truck with platform, crane lifting capacity could option 2ton, 3.2ton, 4ton. the boom type have telescopic and folding boom to choose, the crane brands we have XCMG, SMJ, Sany
Wrecker truck with platform tested pictures:
Our factory main products:
fire truck, road wrecker, aerial working truck, garbage truck, truck mounted crane, refrigerated truck, fuel tanker truck, oil tanker truck, vacuum sewage suction truck, fecal sucking truck, road sweeper, van truck, cargo truck, semi-trailer, tractor, dump truck, concrete mixer truck .............
For more information please contact
Jessica Song
Cell: 0086-18771385883 or 0086-15071634966
Tel: 0086-722-3330261
Skype: jessicasong0525
Website: www.hbjntruck.en.china.cn
