Food Grade Approval High Temperature Flexible Drinking Water Rubber Hose

Food Grade Approval High Temperature Flexible Drinking Water Rubber Hose thumbnail-1
Food Grade Approval High Temperature Flexible Drinking Water Rubber Hose thumbnail-2
Food Grade Approval High Temperature Flexible Drinking Water Rubber Hose thumbnail-3
Food Grade Approval High Temperature Flexible Drinking Water Rubber Hose thumbnail-4
Food Grade Approval High Temperature Flexible Drinking Water Rubber Hose thumbnail-5
Food Grade Approval High Temperature Flexible Drinking Water Rubber Hose thumbnail-6
Food Grade Approval High Temperature Flexible Drinking Water Rubber Hose photo-1
Food Grade Approval High Temperature Flexible Drinking Water Rubber Hose photo-2
Food Grade Approval High Temperature Flexible Drinking Water Rubber Hose photo-3
Food Grade Approval High Temperature Flexible Drinking Water Rubber Hose photo-4
Food Grade Approval High Temperature Flexible Drinking Water Rubber Hose photo-5
Food Grade Approval High Temperature Flexible Drinking Water Rubber Hose photo-6
Negotiable MOQ: 1000 Meters (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SUNBOW
Model Number:
SB-SRT
Contact Supplier Request Quote Chat Now
Shenzhen Sunbow Insulation Materials Mfg. Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SUNBOW
Model Number SB-SRT
Type Insulation Sleeving
Material Other, Silicone Rubber, Silicone Rubber
Application Other, High Temperature, Coffee Maker, Electric Water Bottle...
Rated Voltage 600V
Tensile Strength >3.5Mpa



Food Grade Approval High Temperature Flexible Drinking Water Rubber Hose

Food Grade Approval High Temperature Flexible Drinking Water Rubber Hose



DESCRIPTION



Food Grade Approval High Temperature Flexible Drinking Water Rubber Hose is extruded by high quality silicone rubber. It is commonly used in contact with foods in accordance with provisions of FDA 21 CFR 177.2600 and in electric insulation. It can be installed in coffee maker, electricwater bottle, or used in electric insulation etc.





SPECIFICATION



Performance

Test Method

Performance Index

Dielectric Strength (KV/mm)

GB/T 1048

≥18

Volume Resistivity (Ω/cm)

GB/T 1410

≥1x1014

Tear Resistance (MPa)

GB/T 1040

≥3.5 MPa

Elongation (%)

GB/T 1040

≥210

Fire Resistance(Flame Retarded Products)

GB/T 2408

FV-1





MODEL



SB-SRT





WORKING TEMPERATURE



-60°c ~ 200°c





DIMENSION



Inside Diameter (mm)

Tolerance(mm)

Thickness and Tolerance

2500V(mm)

4000V(mm)

6000V(mm)

7000V(mm)

φ0.8

0.8±0.10

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ1.0

1.0±0.10

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ1.5

1.5±0.10

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ2.0

2.0±0.10

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ2.5

2.5±0.10

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ3.0

3.0±0.10

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ3.5

3.5±0.10

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ4.0

4.0±0.10

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ4.5

4.5±0.10

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ5.0

5.0±0.20

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ5.5

5.5±0.20

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ6.0

6.0±0.20

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ6.5

6.5±0.20

0.50±0.10

1.00±0.15

1.50±0.20

2.00±0.25

φ7.0

7.0±0.20

—

1.00±0.15

1.50±0.20

2.00±0.25

φ7.5

7.5±0.20

—

1.00±0.15

1.50±0.20

2.00±0.25

φ8.0

8.0±0.25

—

1.00±0.15

1.50±0.20

2.00±0.25

φ9.0

9.0±0.25

—

1.00±0.15

1.50±0.20

2.00±0.25

φ10.0

10.0±0.25

—

1.00±0.15

1.50±0.20

2.00±0.25

φ11.0

11.0±0.30

—

1.00±0.15

1.50±0.20

2.00±0.25

φ12.0

12.0±0.30

—

1.00±0.15

1.50±0.20

2.00±0.25

φ13.0

13.0±0.30

—

1.00±0.15

1.50±0.20

2.00±0.25

φ14.0

14.0±0.30

—

—

1.50±0.20

2.00±0.25

φ15.0

15.0±0.30

—

—

1.50±0.20

2.00±0.25

φ20.0

20.0±0.30

—

—

—

2.50±0.3
