SUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl Tubing

Shenzhen Sunbow Insulation Materials Mfg. Co., Ltd.
SUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl Tubing thumbnail-1
SUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl Tubing thumbnail-2
SUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl Tubing thumbnail-3
SUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl Tubing thumbnail-4
SUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl Tubing thumbnail-5
SUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl Tubing thumbnail-6
SUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl Tubing photo-1
SUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl Tubing photo-2
SUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl Tubing photo-3
SUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl Tubing photo-4
SUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl Tubing photo-5
SUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl Tubing photo-6
US$ 0.01 - 6.69 MOQ: 1000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SUNBOW
Model Number:
SB-PVC
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SUNBOW
Model Number SB-PVC
Type Insulation Sleeving
Material Other, PVC, PVC
Application Other, High Voltage, Electric appliances, transformers, motors, wire harness
Rated Voltage 600V/300V
Tensile Strength 10.4Mpa

SUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl Tubing



1. Model

SB-PVC



2. Working temperature

-30~105C



3. Structure

SUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl Tubing adopts high quality eco-friendly PVC and it is processed in dry circumstances. It is shaped by heating and melting with an extruder. And then it is packed in roll after cooling.



4. Characteristics

1) working temperature: -30~105C

2) good flexibility, mechanical property, insulation and flammability

3) pressure endurance grade: 300V/600V

4) temperature grade: UL224

5) CUL, RoHS,REACH certifications



5. Specification

Item

Unit

         Test  Method

Numerical Value

SB-300

SB-600

Voltage rating

V



300

600

Temperature rating

℃

UL224

105

Voltage resistance

Before aging



UL224  23℃

2500V/60sec

After aging

UL224  136℃ 168hr

2500V/60sec

Volume resistivity

Ωcm

UL224

≥1010

Tensile strength

Before aging

Mpa

UL224  23℃

≥10.4

After aging

Mpa

UL224  136℃ 168hr

≥7.3

 Elongation

Before aging

%

UL224  23℃

≥100%

After aging

%

UL224  136℃ 168hr

≥100%

Flexibility



UL224  136℃ 168hr

No cracking

Heat shock



UL224  180℃ 4hr

No cracking

Cold bend



UL224 -30℃ 1hr

No cracking

Copper stability



UL224  136℃ 168hr

No corrosion

Flame resistance



UL224

VW-1



6. Dimension

(One)The British system series of AWG



AWG No.





I.D.(mm)



Wall Thickness (mm)



Package size(m/r)



SB-300

SB-600

24

0.55±0.1

0.25±0.05

0.40±0.05

305

22

0.65±0.1

0.25±0.05

0.40±0.05

305

20

0.85±0.1

0.25±0.05

0.40±0.05

305

19

0.9±0.1

0.30±0.05

0.40±0.05

305

18

1.0±0.15

0.30±0.05

0.45±0.05

305

17

1.2±0.15

0.30±0.05

0.45±0.05

305

16

1.3±0.15

0.30±0.05

0.45±0.05

305

15

1.5±0.15

0.30±0.05

0.45±0.05

305

14

1.7±0.15

0.30±0.05

0.45±0.05

305

13

1.9±0.2

0.30±0.05

0.45±0.05

305

12

2.1±0.2

0.35±0.05

0.50±0.05

305

11

2.4±0.2

0.35±0.05

0.50±0.05

305

10

2.7±0.2

0.35±0.05

0.50±0.05

305

9

3.0±0.2

0.40±0.05

0.50±0.05

305

8

3.3±0.2

0.40±0.05

0.50±0.05

305

7

3.7±0.2

0.40±0.05

0.50±0.05

305

6

4.2±0.3

0.45±0.05

0.50±0.05

305

5

4.7±0.3

0.45±0.05

0.55±0.05

305

4

5.3±0.3

0.45±0.05

0.55±0.05

305

3

5.9±0.3

0.45±0.05

0.55±0.05

305

2

6.6±0.3

0.45±0.05

0.55±0.05

152

1

7.4±0.35

0.45±0.05

0.55±0.55

152

0

8.3±0.35

0.45±0.05

0.55±0.55

152



(Two)  The British system series



Size (inch)



I.D.(mm)

Wall thickness(mm)



Packing size (m/r)

SB-300

 SB-600

5/16

8.0±0.35

0.45±0.05

0.55±0.05

152

3/8

9.5±0.35

0.50±0.05

0.55±0.05

152

7/16

11.1±0.35

0.55±0.10

0.65±0.10

152

1/2

12.7±0.35

0.55±0.10

0.65±0.10

152

9/16

14.3±0.4

0.65±0.10

0.75±0.10

76

5/8

16.0±0.4

0.65±0.10

0.75±0.10

76

3/4

19.0±0.4

0.65±0.10

0.75±0.10

76

7/8

22.0±0.5

0.75±0.15

0.85±0.15

76

1

25.0±0.5

0.75±0.15

0.85±0.15

76

0

27.0±0.8

0.75±0.15

0.85±0.15

76



(Three) The British system series



I.D.(mm)



Wall thickness(mm)



Packing size (m/r)

SB-300

 SB-600

0.80±0.1

0.25±0.05

0.40±0.05

500

1.0±0.1

0.30±0.05

0.40±0.05

500

1.5±0.1

0.33±0.05

0.45±0.05

400

2.0±0.2

0.33±0.05

0.50±0.05

400

2.5±0.2

0.35±0.05

0.50±0.05

300

3.0±0.2

0.40±0.05

0.50±0.05

300

3.5±0.2

0.40±0.05

0.50±0.05

300

4.0±0.2

0.45±0.05

0.55±0.05

300

4.5±0.3

0.45±0.05

0.55±0.05

300

5.0±0.3

0.45±0.05

0.55±0.05

300

6.0±0.3

0.45±0.05

0.55±0.05

300

7.0±0.3

0.45±0.05

0.55±0.05

150

8.0±0.35

0.45±0.05

0.55±0.05

150

9.0±0.35

0.50±0.05

0.60±0.05

150

10.0±0.35

0.55±0.10

0.65±0.10

150

11.0±0.40

0.55±0.10

0.65±0.10

150

12.0±0.40

0.55±0.10

0.65±0.10

150

13.0±0.40

0.55±0.10

0.65±0.10

150

14.0±0.40

0.55±0.10

0.65±0.10

150

15.0±0.40

0.60±0.10

0.70±0.10

50

16.0±0.40

0.60±0.10

0.70±0.10

50

17.0±0.40

0.60±0.10

0.70±0.10

50

18.0±0.40

0.60±0.10

0.70±0.10

50

19.0±0.40

0.65±0.10

0.75±0.10

50

20.0±0.50

0.65±0.10

0.75±0.10

50

21.0±0.50

0.65±0.10

0.75±0.10

50

22.0±0.50

0.70±0.10

0.80±0.10

50

23.0±0.50

0.70±0.10

0.80±0.10

50

24.0±0.50

0.75±0.10

0.85±0.10

50

25.0±0.50

0.75±0.10

0.85±0.10

50

26.0±0.50

0.85±0.10

0.85±0.10

50



7. Application

SUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl Tubing has good flexibility, mechanical property, insulation and flammability. It is widely used in electric appliances, transformers, motors, lights, wires, electric components and wire harness.



8. More pictures

SUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl TubingSUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl Tubing



9. Our services

1) 3~5 workdays of delivery

2) 2 years quality guarantee

3) prompt feedback

4) 24hrs on line service



10. About Sunbow

Shenzhen SUNBOW Insulation Materials MFG. Co., Ltd is one of the leading insulation sleeving manufacturers in China. It was established in 2003. In 2008, due to the business expansion, it is relocated in Heshuikou SUNBOW industrial park. In 2009, we succeeded in getting ISO9001:2008 quality management system certification. We specialize in fiberglass sleevings, PE heat shrink tubes, PVC heat shrink tubes, PTFE heat shrink tubes and silicone rubber tubes. Our products have passed UL, CSA, RoHS, REACH certifications. Our business partners can be found all over the world. Some famous partners are:

SEB, Philips, Zoppas, Toshiba, Sanyo, SAMSUNG, Midea, HOT, IKEA, Breville, Panasonic, Tescon, Tiger, Emerson, Conair....

SUNBOW VW-1 Flexible Flame Retardant Insulation PVC Clear Vinyl Tubing



11. How to Contact Us

Trade manager: cn1511744528

Skype: Sarah.sunbow

W: www. sunbowgd. com

Tel: +86-755-2716 0885-808(Ext)

Fax: +86-755-2716 0895



12. Other Services

Free samples can be provided for your trial.
