UL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic Tube

UL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic Tube thumbnail-1
UL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic Tube thumbnail-2
UL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic Tube thumbnail-3
UL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic Tube thumbnail-4
UL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic Tube thumbnail-5
UL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic Tube thumbnail-6
UL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic Tube photo-1
UL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic Tube photo-2
UL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic Tube photo-3
UL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic Tube photo-4
UL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic Tube photo-5
UL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic Tube photo-6
US$ 0.1 - 3.23 MOQ: 500 Meters
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SUNBOW
Model Number:
SB-PTFE
Contact Supplier Request Quote Chat Now
Shenzhen Sunbow Insulation Materials Mfg. Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SUNBOW
Model Number SB-PTFE
Type Insulation Sleeving
Material Other, PTFE resin, PTFE
Application High Voltage
Tensile Strength >25Mpa

UL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic Tube



UL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic Tube



1. Model

SB-PTFE



2. Working Temperature

-80~260C



3. Structure

UL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic Tube adopts imported high quality PTFE resin by extruding and burning.



4. Characteristics

1) working temperature: -80~260C

2) voltage resistance: 45kv/mm

3) relative density: 2.14~2.20

4) melting point: 327C

5) high temperature, high voltage, anticorrosion, wearproof, self-lubrication

6) CUL, REACH, RoHS certifications



5. Specification

Item

Standard

Item

Standard

Relative Density

2.14~2.20

Melting Point (0C)

327

Tensile Strength (MPa)

≥25

Operating Temperature (0C)

-80~260

Stretch Yield Strength (MPa)

≥11

Oxygen index(%)

>90

Elongation (%)

≥300

Water Absorption (%)

<0.01

Arc Resistance

>300

Linear Expansion Coefficient (×105/0C)21~1000C

10

Shore Hardness (D)

59~63

breakdown strength (kv/mm)

≥45





volume resistance (Ω.cm)

1×1016



6. Dimension

AWG

I.D.(mm)

O.D.(mm)(s)

O.D.(mm)(T)

O.D.(mm)(L)

Standard Package

(meter/roll)

30

0.30±0.10

0.80±0.10

0.70±0.10

0.64±0.10

305

28

0.38±0.10

0.88±0.10

0.78±0.10

0.72±0.10

305

26

0.46±0.10

0.96±0.10

0.86±0.10

0.80±0.10

305

24

0.56±0.10

1.16±0.10

1.06±0.10

0.90±0.10

305

23

0.66±0.10

1.26±0.10

1.16±0.10

1.00±0.10

305

22

0.71±0.10

1.31±0.10

1.21±0.10

1.05±0.10

305

21

0.81±0.10

1.41±0.10

1.31±0.10

1.15±0.10

305

20

0.86±0.10

1.66±0.10

1.46±0.10

1.20±0.10

305

19

0.96±0.20

1.76±0.20

1.56±0.20

1.30±0.20

200

18

1.07±0.20

1.87±0.20

1.67±0.20

1.41±0.20

200

17

1.19±0.20

1.99±0.20

1.79±0.20

1.53±0.20

200

16

1.34±0.20

2.14±0.20

1.94±0.20

1.68±0.20

153

15

1.50±0.20

2.30±0.20

2.10±0.20

1.84±0.20

153

14

1.68±0.20

2.48±0.20

2.28±0.20

2.08±0.20

100

13

1.93±0.20

2.73±0.20

2.53±0.20

2.33±0.20

100

12

2.16±0.25

2.96±0.25

2.76±0.25

2.56±0.25

100

11

2.41±0.25

3.21±0.25

3.01±0.25

2.81±0.25

150

10

2.69±0.25

3.49±0.25

3.29±0.25

3.09±0.25

150

9

3.00±0.25

4.00±0.25

3.80±0.25

3.40±0.25

150

8

3.38±0.25

4.38±0.25

4.18±0.25

3.78±0.25

100

7

3.76±0.25

4.76±0.25

4.56±0.25

4.16±0.25

100

6

4.22±0.25

5.22±0.25

4.92±0.25

4.80±0.25

100

5

4.72±0.25

5.72±0.25

5.42±0.25

5.32±0.25

50

4

5.28±0.30

6.28±0.30

6.02±0.30

5.88±0.25

1

3

5.94±0.30

6.94±0.30

6.74±0.30

6.54±0.25

1

2

6.68±0.30

7.68±0.30

7.48±0.30

7.28±0.25

1

1

7.46±0.30

8.46±0.30

8.26±0.30

8.06±0.25

1

0

8.38±0.30

9.38±0.30

9.18±0.30

8.98±0.25

1



7. Application

UL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic Tube has the advantages of high temperature resistance, high voltage resistance, anticorrosion, wearproof and good self-lubrication. It is widely used in machinery, electric appliances, automobiles, aeroplanes, chemical industry and communications.



8. More Pictures

UL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic TubeUL High Temperature Resistant Semi-rigid Antiwear Small Clear Plastic Tube



9. Our Services

1) 3~5 workdays of delivery

2) 2 years quality guarantee

3) prompt feedback

4) 24hrs on line service



10. About Sunbow

1) 10-year exporting experience

2) 15-year manufacturing experience

3) ISO9001:2008 certificate

4) product certifications: CUL, REACH, RoHS

5) business partners:

Sanyo, Panasonic & Tiger, SEB, Philips, Black & Decker, Emerson & Conair, HOT, IKEA and Midea
