High Temperature High Pressure Resistant White PTFE Tube For Insulating Cover Conductor

High Temperature High Pressure Resistant White PTFE Tube For Insulating Cover Conductor thumbnail-1
High Temperature High Pressure Resistant White PTFE Tube For Insulating Cover Conductor thumbnail-2
High Temperature High Pressure Resistant White PTFE Tube For Insulating Cover Conductor thumbnail-3
High Temperature High Pressure Resistant White PTFE Tube For Insulating Cover Conductor thumbnail-4
High Temperature High Pressure Resistant White PTFE Tube For Insulating Cover Conductor thumbnail-5
High Temperature High Pressure Resistant White PTFE Tube For Insulating Cover Conductor thumbnail-6
High Temperature High Pressure Resistant White PTFE Tube For Insulating Cover Conductor photo-1
High Temperature High Pressure Resistant White PTFE Tube For Insulating Cover Conductor photo-2
High Temperature High Pressure Resistant White PTFE Tube For Insulating Cover Conductor photo-3
High Temperature High Pressure Resistant White PTFE Tube For Insulating Cover Conductor photo-4
High Temperature High Pressure Resistant White PTFE Tube For Insulating Cover Conductor photo-5
High Temperature High Pressure Resistant White PTFE Tube For Insulating Cover Conductor photo-6
US$ 0.0333 - 2.6666 MOQ: 2000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SUNBOW
Model Number:
SB-PTFE
Contact Supplier Request Quote Chat Now
Shenzhen Sunbow Insulation Materials Mfg. Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SUNBOW
Model Number SB-PTFE
Type Insulation Sleeving
Material Other, PTFE, PTFE
Application Other, High Temperature, Mechanical Application, Motor...
Rated Voltage >25.0 Mpa



High Temperature High Pressure Resistant White PTFE Tube For Insulating Cover Conductor



PRODUCT INTRODUCTION

High Temperature High Pressure Resistant White PTFE Tube For Insulating Cover Conductor is manufactured by extrusion process with imported high quality PTFE resin. It has excellent high temperature resistance, high voltage resistance, abrasion resistance and self-lubricating properties. It widely used in mechanical industries, electronic and electric products, motor vehicle, aerospace, chemical industry, communications etc.



High Temperature High Pressure Resistant White PTFE Tube For Insulating Cover Conductor



WORKING TEMPERATURE

-80°c ~ 260°c



CHARACTERISTICS

1. Excellent anti-corrosion (anti-acid/alkaline/chemical/oil);

2. High voltage resistance (45KV/mm)



SPECIFICATION

Item

Standard

Item

Standard

Relative Density

2.14~2.20

Melting Point (ºC)

327

Tensile Strength (MPa)

≥25

Operating Temperature (0C)

-80~260

Stretch Yield Strength (MPa)

≥11

Oxygen Index (%)

>90

Elongation (%)

≥300

Water Absorption (%)

<0.01

Arc Resistance

>300

Linear Expansion Coefficient (×105/ ºC)21~1000C

10

Shore Hardness (D)

59~63

breakdown strength (KV/mm)

≥45

Volume Resistance (Ω. cm)

1*1016







DIMENSION

AWG

Inside Diameter  (mm)

Outside Diameter (mm)(S)

Outside Diameter (mm)(T)

Outside Diameter (mm)(L)

Standard Package

(m/roll)

30

0.30±0.10

0.80±0.10

0.70±0.10

0.64±0.10

305

28

0.38±0.10

0.88±0.10

0.78±0.10

0.72±0.10

305

26

0.46±0.10

0.96±0.10

0.86±0.10

0.80±0.10

305

24

0.56±0.10

1.16±0.10

1.06±0.10

0.90±0.10

305

23

0.66±0.10

1.26±0.10

1.16±0.10

1.00±0.10

305

22

0.71±0.10

1.31±0.10

1.21±0.10

1.05±0.10

305

21

0.81±0.10

1.41±0.10

1.31±0.10

1.15±0.10

305

20

0.86±0.10

1.66±0.10

1.46±0.10

1.20±0.10

305

19

0.96±0.20

1.76±0.20

1.56±0.20

1.30±0.20

200

18

1.07±0.20

1.87±0.20

1.67±0.20

1.41±0.20

200

17

1.19±0.20

1.99±0.20

1.79±0.20

1.53±0.20

200

16

1.34±0.20

2.14±0.20

1.94±0.20

1.68±0.20

153

15

1.50±0.20

2.30±0.20

2.10±0.20

1.84±0.20

153

14

1.68±0.20

2.48±0.20

2.28±0.20

2.08±0.20

100

13

1.93±0.20

2.73±0.20

2.53±0.20

2.33±0.20

100

12

2.16±0.25

2.96±0.25

2.76±0.25

2.56±0.25

100

11

2.41±0.25

3.21±0.25

3.01±0.25

2.81±0.25

150

10

2.69±0.25

3.49±0.25

3.29±0.25

3.09±0.25

150

9

3.00±0.25

4.00±0.25

3.80±0.25

3.40±0.25

150

8

3.38±0.25

4.38±0.25

4.18±0.25

3.78±0.25

100

7

3.76±0.25

4.76±0.25

4.56±0.25

4.16±0.25

100

6

4.22±0.25

5.22±0.25

4.92±0.25

4.80±0.25

100

5

4.72±0.25

5.72±0.25

5.42±0.25

5.32±0.25

50

4

5.28±0.30

6.28±0.30

6.02±0.30

5.88±0.25

1

3

5.94±0.30

6.94±0.30

6.74±0.30

6.54±0.25

1

2

6.68±0.30

7.68±0.30

7.48±0.30

7.28±0.25

1

1

7.46±0.30

8.46±0.30

8.26±0.30

8.06±0.25

1

0

8.38±0.30

9.38±0.30

9.18±0.30

8.98±0.25

1



High Temperature High Pressure Resistant White PTFE Tube For Insulating Cover ConductorHigh Temperature High Pressure Resistant White PTFE Tube For Insulating Cover ConductorHigh Temperature High Pressure Resistant White PTFE Tube For Insulating Cover ConductorHigh Temperature High Pressure Resistant White PTFE Tube For Insulating Cover ConductorHigh Temperature High Pressure Resistant White PTFE Tube For Insulating Cover ConductorHigh Temperature High Pressure Resistant White PTFE Tube For Insulating Cover Conductor
