Specifications
4cbm forland small mixer truckfoton chassis
drive type: 4x2
engine power 130ps
factory sale
4cbm Forland small mixer truck
Features of this small mixer truck
1. Suit to transport cement through narrow street road, country road.
2. Fitted with Yuchai brand engine, meet Euro 2 emission standard, have a good climb slope ability.
Vehicle name |
Forland small mixer truck 4cbm |
||
Manufacturer |
Hubei Jiangnan Special Automobile Co., Ltd |
||
Cab |
Has sleeper bed, 3 seats, air conditioner |
||
Drive type |
4x2, left hand drive |
||
Wheel base |
3400 mm |
||
Overall dimension (L*W*H) |
6460 X 2255 X 3300 mm |
||
GVW |
13570 kg |
||
Curb weight |
5980 kg |
||
Rated payload weight |
7460 kg |
||
Engine |
Engine model |
YC4D130-33 |
|
Engine make |
Yuchai Power |
||
Rated power |
96 kw (130hp) / 2800rpm |
||
Max torque |
420N.m / 1400-1800rpm |
||
Displacement |
4214 ml |
||
Emission standard |
Euro 2 |
||
Type |
Diesel engine, 4 cylinders in line, turbo charged, water cooling, 4 stroke, direct injection |
||
Tire type |
8.25-20 |
||
Tire number |
6 pcs +1 spare tyre |
||
Gear box |
145HF, 5 speed, Manual, 5 speed forward & 1 speed reverse |
||
Rear axle load capacity |
9 ton |
||
Wheel track (F/R) |
1963/1860 |
||
Leaf spring number |
10/10 |
||
Performance |
Mixing volume |
4cbm |
|
Filling ratio |
0.63% |
||
Feeding speed |
≥3 (m³/min) |
||
Discharging speed |
≥2 (m³/min) |
||
Discharge residue |
< 1% |
||
Agitator rotating speed |
0-12 r/min |
||
Tilt angle |
13º |
||
Drum material |
16MnQ345 , thickness 5-6mm , head thickness 6-8mm |
||
Forland is a sub-brand of Foton, we supply forland 3.5cbm concrete mixer truck, 4cbm cement mixer truck, 5-6cbm mixer truck, Foton Auman 6x4 concrete mixer truck, Foton Auman 8x4 cement mixer truck, with drum load capacity 8cbm, 9cbm, 10cbm, 12cbm, 14cbm, 16cbm.
Our main products:
fire truck, aerial work platform truck, garbage truck, truck mounted crane, refrigerated truck, road sweeper, fuel tanker truck, water tanker truck, vacuum sewage suction truck, fecal sucking truck, road wrecker, dump truck, concrete mixer truck, semi-trailer, tractor truck, van truck, cargo truck
For more details of mixer truck, concrete mixer truck, cement mixer truck please kindly email us or call us, thank you.
