Jinbei 4x2 cargo truck dimensions
we supply all brand of cargo truck, foton cargo truck, jac cargo truck, jmc cargo truck, faw cargo truck, shacman cargo truck, sinotruck cargo truck, dongfeng cargo truck ............some of models availble in right hand drive, some have diesel engine and gasoline engine optional.
Vehicle brand |
Jinbei 4x2 cargo truck dimensions |
|
Vehicle model |
SY1023DM5F |
|
Cabin |
single row cabin, radio, optional power steering, a/c |
|
Whole vehicle main dimensions |
Overall dimensions (LxWxH)mm |
4770×1850×2100 |
Inner dimensions of the cargo body (LxWxH)mm |
3250×1680×380 |
|
Driving type |
4×2, LHD |
|
Wheel base (mm) |
2515 |
|
Wheel track (front/rear) (mm) |
1390/1400 |
|
Weight data |
Curb weight (kg) |
1510 |
Rated payload (kg) |
795 |
|
Persons in cab (persons) |
2 |
|
Gross vehicle weight(kg) |
2500 |
|
Max. speed(km/h) |
80 |
|
Engine |
Model |
4B22TC1 |
Type |
Diesel engine |
|
Displacement(ml) |
2156 |
|
Rated power(kw/rpm) |
56kw / 75ps |
|
Gearbox |
Model |
manual, 5 speed |
Rear axle |
2 ton |
|
Tire type |
6.00-14 |
|
Tire number |
6pcs |
|
brake |
Oil brake |
|
Leaf spring number |
7/5+5 |
|
Approach / Departure angle (°) |
27/17.5 |
|
Suspension (Front / Rear) |
1015/1580 |
|
Our factory certificates show:
Customer visit our factory:
Our factory main products:
fire truck, aerial platform truck, road wrecker / tow truck, garbage truck, truck mounted crane, refrigerated truck, sewage suction truck, fecal sucking truck, fuel tanker truck, water tanker truck, van truck, cargo truck, tractot, dump truck, semi-trailer, concrete mixer truck
Hubei Jiangnan Special Automobile Co., Ltd
Website: www.hbjntruck.en.china.cn
Skype: jessicasong0525
Tel: 0086 722 3330261
Cell: 0086 18771385883 or 0086-15071634966
