Product Details
| Place of Origin | Guangdong, China | Brand Name | Sunbow | |
| Model Number | SB-PVDF-HST | Type | Insulation Sleeving | |
| Material | Other, PVDF | Application | High Temperature | |
| Rated Voltage | 600V | Tensile Strength | >20.5Mpa |
Product Description
Excellent abrasion withstand 1mm Kynar 175C PVDF heat shrink tubes
Description
175°C high temperature Chemical resistant PVDF tubing (Kynar® tube)
Seni-rigid thin wall Kynar®* heat shrink tubing,ideal for electronic,automotive and military applications requiring protection and see-through inspection
Usage
It is widely used in electrical, computer, electro thermal, aerospace, military, and telecommunication etc.
Features
- High withatand to abrasion and cut-through.
- Excellent chemical and solvent resistance.
- Continuous Operating Temperature:-55°C to 175°C.
- Shrink Temperature:175°C.
- *Kynar®is a registered trademark of ATOFINA.
Technical Data
Item | Test Method | Unit | Specifications |
Min.shrinktemperature | - | °C | 155 |
Operation temperature | - | °C | -55~175 |
Specific Gravity | ASTM D792 | g/cm3 | 1.78 |
Tensile strength | ASTM D2671 | M Pa | ≥25 |
Elongation at break | ASTM D2671 | % | ≥550 |
After Aging Elongation | 250°C,168h | % | ≥500 |
Heat Shock | 300°C,4h | - | -No Cracking- |
Cold Bend | -55°C,4h | - | -No Cracking- |
Volume Resistivity | ASTM D257 | Ω.cm | ≥1014 |
Flammability Rating | UL-224 | VW-1 | Pass |
Dimension(2:1)
size | Assupplied(mm) | After recovery(mm) | Standard Package | ||
inch | mm | Internal Diameter(mm) | Internal Diameter (mm) | Wall T Thickness(mm) | Spool Length M/Spool |
3/64 | 1.2 | 1.2 | 0.6 | 0.25±0.05 | 200 |
1/16 | 1.6 | 1.6 | 0.8 | 0.25±0.05 | 200 |
3/32 | 2.4 | 2.4 | 1.2 | 0.25±0.05 | 200 |
1/8 | 3.2 | 3.2 | 1.6 | 0.25±0.05 | 100 |
3/16 | 4.8 | 4.8 | 2.4 | 0.25±0.05 | 100 |
1/4 | 6.4 | 6.4 | 3.2 | 0.30±0.05 | 100 |
3/8 | 9.5 | 9.5 | 4.8 | 0.30±0.05 | 50 |
1/2 | 12.7 | 12.7 | 6.4 | 0.30±0.05 | 50 |
3/4 | 19.1 | 19.1 | 9.5 | 0.42±0.05 | 50 |
1 | 25.4 | 25.4 | 12.7 | 0.50±0.05 | 50 |
1-1/2 | 38.1 | 38.1 | 19.1 | 0.50±0.05 | 50 |
1) 3~5 quick time production;
2) 2 years quality guarantee;
3) Prompt feedback;
4) 24 hours on line servic.
5) Free sample for your approval
Q : Are you a factory or trading company ?
A: We are a factory , can offer best quality product and reasonable price for you
Q: Can you accept sample order?
A: Yes, we accept samples with little and reasonable charge.
Q: What is your MOQ?
A: Normally,500 Meter per color.
Q:What is your delivery time?Can we short it in 7 days or less?
A: 3 days for sample, 3-25 days for mass production. (depend quantity)
Q: What is your payment terms?
A: T/T,Paypal(3% surcharge),Western Union
Q: How can I get my order?How can I know you sent the goods.
A: We will send you the goods by UPS, DHL, Fedex, Oversea Shipment or other forwarder, all with tracking number.
Q:How about your quality?
A: Try a small order, you will have your judgement!
