With ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink Tube

With ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink Tube thumbnail-1
With ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink Tube thumbnail-2
With ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink Tube thumbnail-3
With ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink Tube thumbnail-4
With ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink Tube thumbnail-5
With ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink Tube thumbnail-6
With ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink Tube photo-1
With ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink Tube photo-2
With ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink Tube photo-3
With ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink Tube photo-4
With ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink Tube photo-5
With ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink Tube photo-6
US$ 0.7721 - 8.88 MOQ: 1000 Meters
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Sunbow
Model Number:
SB-SBRSW & SB-RSFRW
Contact Supplier Request Quote Chat Now
Shenzhen Sunbow Insulation Materials Mfg. Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Sunbow
Model Number SB-SBRSW & SB-RSFRW
Type Insulation Sleeving
Material Other, PE, Polyolefin
Application High Voltage
Rated Voltage 600V
Tensile Strength 14Mpa

With ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink Tube

 With ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink Tube

1. Model

SB-SBRSW & SB-RSFRW



2. Working Temperature

-45~125C



3. Structure

With ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink Tube is composed of polyolefin. It has excellent insulation, sealing, mechanical wearproof resistance, dampproof and shock resistance properties.



4. Characteristics

1) shrink ratio: 3:1

2) shrink temperature: 70~125C

3) working temperature: -45~125C

4) good insulation, sealing, mechanical wearproof resistance, dampproof and shock resistance properties

5) CUL, RoHS, REACH



5. Dimension

Flame retardant heavy wall heat shrinkable tube with adhesive lined specification (3:1)




Size

As supplied

After recovery(mm)

Standard package M/pcs

ID

Outer layer W.T.

Adhesive W.T.

Total W.T.

9/3

≥9

≤3

2.0±0.20

0.35±0.10

2.30±0.25

1.22

13/4

≥13

≤4

2.4±0.20

0.35±0.10

2.75±0.25

1.22

20/6

≥20

≤6

2.5±0.20

0.40±0.10

2.90±0.25

1.22

28/9

≥28

≤9

2.5±0.20

0.40±0.10

2.90±0.25

1.22

33/10.2

≥33

≤10.2

3.2±0.20

0.40±0.10

3.60±0.25

1.22

38.1/12

≥38.1

≤12

3.4±0.20

0.60±0.15

4.00±0.30

1.22

43.2/12

≥43.2

≤12

4.3±0.20

0.70±0.20

5.00±0.35

1.22

51/16

≥51

≤16

4.3±0.20

0.70±0.20

5.00±0.35

1.22

70/21

≥70

≤21

4.3±0.20

0.70±0.20

5.00±0.35

1.22

85/25

≥85

≤25

4.3±0.20

0.70±0.20

5.00±0.35

1.22

105/30

≥105

≤30

4.3±0.20

0.80±0.25

5.10±0.35

1.22

120/39

≥120

≤39

4.3±0.20

0.80±0.25

5.10±0.35

1.22

140/42

≥140

≤42

4.3±0.20

0.80±0.25

5.10±0.35

1.22



Flame retardant heavy wall heat shrinkable tube without adhesive lined specification (3:1)




Size

As supplied (mm)

After recovery(mm)

Standard package M/pcs

ID

Total W.T.

9/3

≥9

≤3

2.30±0.25

1.22

13/4

≥13

≤4

2.75±0.25

1.22

20/6

≥20

≤6

2.90±0.25

1.22

28/9

≥28

≤9

2.90±0.25

1.22

33/10.2

≥33

≤10.2

3.60±0.25

1.22

38.1/12

≥38.1

≤12

4.00±0.30

1.22

43.2/12.7

≥43.2

≤12

5.00±0.35

1.22

51/16

≥51

≤16

5.00±0.35

1.22

70/21

≥70

≤21

5.00±0.35

1.22

85/25

≥85

≤25

5.00±0.35

1.22

105/30

≥105

≤30

5.10±0.35

1.22

120/39

≥120

≤39

5.10±0.35

1.22

140/42

≥140

≤42

5.10±0.35

1.22





6. Application

With ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink Tube can be widely used in electrons, electricity, communicaitons, automobiles, ships and aeroplanes.



7. More Pictures

With ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink TubeWith ISO 9001:2008 Standard UL High Quality Insulation Heavy Wall Halogen Free Heat Shrink Tube



8. Our Services

1) 3~5 workdays of delivery

2) 2 years quality guarantee

3) prompt feedback

4) 24hrs on line service



9. About Sunbow

1) 10-year exporting experience

2) 15-year manufacturing experience

3) ISO9001:2008 quality management system certification

4) product certifications: CUL (E333178---UZIQ2  VW-1; E333177---UZFT2/8  200C  600V); RoHS; REACH

5) business partners:

Sanyo, Panasonic & Tiger, SEB, Philips, Black & Decker, Emerson & Conair, HOT, IKEA and Midea



10. How to Contact Us

Trade manager: cn1511744528

Skype: Sarah.sunbow
