SUNBOW Low Voltage 1500V Polyolefin Various Color Busbar Heat Shrink Tube

Name: SUNBOW Low Voltage 1500V Polyolefin Various Color Busbar Heat Shrink Tube
Brand: SUNBOW
Availability: InStock

FOB Price

USD $0.0412 - $18.3333 / Meter

5000 Meters(Min.Order)

Supply Ability 1000000 Meter / Meters per Month
Port SHENZHEN
Payment Terms:Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:	Guangdong, China	Brand Name:	SUNBOW	Model Number:	SB-RSFR-125H
Type:	Insulation Sleeving	Material:	Other, PE, Polyolefin	Application:	Low Voltage
Rated Voltage:	600V

Product Description

SUNBOW Low Voltage 1500V Polyolefin Various Color Busbar Heat Shrink Tube

MAIN PROPERTIES

1. Halogen free, non-smoke, non-toxic, flame-retardant, soft, quick shrink, stable performance

2. Shrink ratio: 2:1

3. Shrink temperature: 84ºC ~ 120ºC

STRUCTURE

SUNBOW Low Voltage 1500V Polyolefin Various Color Busbar Heat Shrink Tube is made of eco-friendly cross-linking polyolefin material under irradiation. It has environment-friendly, flexible, flame retardant, quick shrink and stable performances. Also, it has electrical insulation, welding point anticorrosion and antirust and mechanical performances. It has passed UL, RoHS, Reach certifications for 300V and 600V.

APPLICATION

SUNBOW Low Voltage 1500V Polyolefin Various Color Busbar Heat Shrink Tube is mainly used in electronics, telecommunication, automobiles, shipping and other manufacturing industries.

SPECIFICATION

Property		Unit	Test Method	Standard
Tensile Strength		MPA	≥10.4(Before Aging)	GB/T 1040
Tensile Strength		MPA	≥7.3(After Aging)	158ºC*168hrs
Breakage Elongation (%)		%	≥200(Before Aging)	GB/T 1040
Breakage Elongation (%)		%	≥100(After Aging)	158ºC*168hrs
Heat Shock		-	No Sticking & No Cracking	250ºC*4hrs
Cold Blend		-	No Cracking	-30ºC*4hrs
Breakdown Strength		KV/mm	≥15	GB/T 1408
Dielectric Withstand	600V	-	Pass	No Breakdown for 2500V, 60s
Dielectric Withstand	300V	-	Pass	No Breakdown for 1500V,60s
Volume Resistivity		Ω. cm	≥1×10¹⁴	GB/T 1410
Corrosion Performance		-	pass	158ºC*168hrs
Copper Stability		-	pass	158ºC*168hrs
Flammability		-	pass	VW-1

DIMENSION

Inner Diameter	As Supplied(mm)		After Recovery(mm)		Standard Package	Application Range(mm)
Inner Diameter	Inner Diameter	Wall Thickness	Inner Diameter	Wall Thickness	(m/spool)	Application Range(mm)
Φ0.6	0.9±0.2	0.20±0.05	≤0.40	0.33±0.10	400	0.4~0.7
Φ0.8	1.1±0.2	0.20±0.05	≤0.50	0.33±0.10	400	0.6~0.8
Φ1.0	1.5±0.2	0.20±0.05	≤0.65	0.36±0.10	400	0.75~0.9
Φ1.5	2.0±0.2	0.20±0.05	≤0.85	0.36±0.10	400	0.95~1.4
Φ2.0	2.5±0.2	0.23±0.05	≤1.00	0.45±0.10	400	1.1~1.8
Φ2.5	3.0±0.2	0.23±0.05	≤1.30	0.45±0.10	400	1.35~2.3
Φ3.0	3.5±0.2	0.23±0.05	≤1.50	0.45±0.10	400	1.6~2.7
Φ3.5	4.0±0.2	0.23±0.05	≤1.80	0.45±0.10	400	1.85~3.2
Φ4.0	4.5±0.2	0.25±0.05	≤2.00	0.45±0.10	400	2.1~3.6
Φ4.5	5.0±0.2	0.28±0.05	≤2.30	0.56±0.10	200	2.35~4.0
Φ5.0	5.5±0.2	0.28±0.05	≤2.50	0.56±0.10	200	2.6~4.5
Φ6.0	6.5±0.2	0.28±0.05	≤3.00	0.56±0.10	200	3.1~5.4
Φ7.0	7.5±0.3	0.28±0.05	≤3.50	0.56±0.10	100	3.7~6.3
Φ8.0	8.5±0.3	0.30±0.08	≤4.00	0.56±0.10	100	4.2~7.2
Φ9.0	9.5±0.3	0.30±0.08	≤4.50	0.56±0.10	100	4.7~8.0
Φ10	10.5±0.3	0.30±0.08	≤5.00	0.56±0.10	100	5.2~9.0
Φ11	11.5±0.3	0.30±0.08	≤5.50	0.56±0.10	100	5.7~10
Φ12	12.5±0.3	0.30±0.08	≤6.00	0.56±0.10	100	6.2~11
Φ13	13.5±0.3	0.30±0.08	≤6.50	0.56±0.10	100	6.7~12
Φ14	14.5±0.3	0.35±0.10	≤7.00	0.70±0.10	100	7.3~13
Φ15	15.5±0.4	0.35±0.10	≤7.50	0.70±0.10	100	7.8~14
Φ16	16.5±0.4	0.35±0.10	≤8.00	0.70±0.10	100	8.3~15
Φ17	17.5±0.4	0.35±0.10	≤8.50	0.70±0.10	100	8.8~16
Φ18	19.0±0.5	0.35±0.10	≤9.00	0.70±0.10	100	9.3~17
Φ20	22.0±0.5	0.35±0.10	≤10.00	0.83±0.15	100	10.4~19
Φ22	24.0±0.5	0.40±0.12	≤11.00	0.83±0.15	100	11.4~21
Φ25	26.0±0.5	0.40±0.12	≤12.50	0.90±0.15	50	12.8~24
Φ28	29.0±0.5	0.45±0.12	≤14.00	0.90±0.15	50	14.4~29
Φ30	31.5±1.0	0.45±0.12	≤15.00	1.00±0.15	50	16~29
Φ35	36.5±1.0	0.45±0.12	≤17.50	1.00±0.15	50	18~34
Φ40	41.5±1.0	0.45±0.12	≤20.00	1.00±0.15	50	21~39
Φ45	46.5±1.0	0.50±0.15	≤22.5	1.00±0.15	25	23.5~44
Φ50	≥50	0.50±0.15	≤25.0	1.10±0.15	25	26~49
Φ60	≥60	0.60±0.15	≤30.0	1.20±0.15	25	35~55
Φ70	≥70	0.65±0.15	≤35.0	1.30±0.20	25	40~65
Φ80	≥80	0.65±0.15	≤40.0	1.30±0.20	25	45~75
Φ90	≥90	0.65±0.15	≤45.0	1.30±0.20	25	50~85
Φ100	≥100	0.65±0.20	≤50.0	1.30±0.20	25	55~95
Φ120	≥120	0.65±0.20	≤60.0	1.30±0.20	25	65~115
Φ150	≥150	0.65±0.20	≤70.0	1.30±0.20	25	80~145
Φ180	≥180	0.65±0.30	≤90.0	1.30±0.30	25	95~175
Φ210	≥210	0.65±0.30	≤105.0	1.30±0.30	25	110~205
Φ230	≥230	0.65±0.30	≤115.0	1.30±0.30	25	120~225
Φ250	≥250	0.65±0.30	≤125.0	1.30±0.30	25	130~240

FREQUENTLY ASKED QUESTIONS

Q1. You are a factory or trading company?

We are a factory and we can provide best price and high quality products for you.

Q2. Can you accept sample orders?

Yes, we can accept sample orders and we can also provide free samples for your test if necessary.

Q3. What is your MOQ?

Normally, 1000m per size.

Q4. What are your payment terms?

T/T 100% or West Union

Q5. How can I get my order? How can I know you sent the goods?

We will send the goods by UPS, DHL, FedEx or sea shipment. After we sent the goods , we will give you the tracking number or other relative files for your check.

Q6. How about your quality?

Try a small order, and then you can judge.

Q7. Have you passed any certificates?

Yes. We are an ISO9001:2008 quality management system certificated manufacturer. Our products have passed UL, ROHS, REACH certifications. If necessary, we can send you relative files.

Q8. Are there any advantages to choose your products?

1) ISO 9001 : 2008 TS 16949 standard factory manufacturer

2) high-tech enterprise in China

3) with 12-year manufacturing experience

4) factory direct sales

5) best price high quality product

6) quick delivery time

7) quick response for feedback

8) few complaints from customers

9) more competitive price for VIP customers

10) convenient situation near to seaport

YOU CAN SEND YOUR DETAILED INQUIRY FOR FREE SAMPLES AND PLEASE CLICK "SEND" NOW!
