Speaker Components Driver

Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Model Number:

SW-15031C

Place of Origin:

Guangdong, China

Guangzhou Baisheng Audio Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Model Number SW-15031C

Place of Origin Guangdong, China

speaker components SW-15031C woofer 600W,4inch voice coil

600W continuous program power capacity 75.5mm copper voice coil 41-3500 Hz response 97 dB Sensitivity

Specifications
Nominal Diameter	390mm(15in)
Nominal Impedance	8Ω
Minimum Impedance	7.2Ω
Power Handling	Power Handling
(50-500 Hz)
Nominal	600W
Continuous Program	1200W
Sensitivity (1W/1m)	98dB
Frequency Range	41-3500 Hz
Voice Coil Diameter	75.5mm
Winding Material	Aluminium
Former Material	KSV
Winding Depth	14mm
Magnetic Gap Depth	10mm
Flux Density	1.15T

Also available in 16Ω, data upon request
Thiele & Small Parameters
Fs	41 Hz
Re	5.8Ω
Qes	0.38
Qms	10.4
Qts	0.37
Vas	173dm3
n 0	3.10%
X max	±2mm
X var	±3mm
Mms	110g
B1	20.8Tm
Le	0.9mH
Mounting and Shipping Information
Overall Diameter	410mm
Bo 1t Circle Diameter	391mm
Baffie Cutout Diameter	356mm
Ddepth	170mm
F 1 ange and Gasket Thickness	14mm
Net Weight	10.5kg
Shipping Weight	11.5kg
Shipping BOX	400×400×200mm
2hours test made with continuous pink noise signal(6 dB crest factor) within the speicifled range, Power calculated on rated minimum impedance, Loudspeaker mounted In 35 liters(1.25ft3) bass-refiex box, tuned at 65Hz.
Power on Continuous Program is defined as 3 dB greater than the Nominal rating.
Applied RMS Voltage is set to 2.83V for 8 ohms Nominal impedance, average SPL from 200 to 4000 Hz.
Thiele-Small parameters are measured after a high level 20 Hz sine wave preconditioning test.
