[ Factory, EXW price, quickly shipment, alibaba trade assurance, 10 years of OEM ]:
F15+ loudspeaker descriptions:
1. The high power F15+ is a high performance, wide-bandwidth system in an incredibly compact and efficient package.
2. Extended frequency response is provided by a powerful 15''(380mm) low frequency driver and a 1.4''(38mm) HF compression driver mounted on a rotatable 80° x 50° constant directivity HF horn.
3. The F15+ is perfect for higher power applications where ease of installation or speed of development are important factors.
F15+ loudspeaker features:
1.High performance, passive 2-way full range system, 1x15''LF + 1x3''HF, 450W - 900W high power.
2. Full sound, powerful bass, low distortion, pure and natural tone quality, light weight, easy to install and safely.
3. Best chioce for nightclubs, bars, Disco, theaters,church, concert halls, Band, stage performance, wedding, touring performance, etc.
F15+ loudspeaker specifications:
| TYPE | Compact, two-way passive |
| FREQUENCY | 55Hz-18kHz±3dB |
| DRIVERS | LF: 1x 15″(380mm) bass driver, Neodymium driver HF: Voice coil HF driver size 3''(72mm), Ferrite driver |
| RATED POWER | 450W RMS,900W peak |
| SENSITIVITY | 99dB |
| MAXIMUM SPL | 124dB contiuous, 130dB peak |
| NOMINAL IMPEDANCE | 8 ohms |
| DISPERSION (-6dB) | 80°horizontal, 50°vertical |
| CONNECTORS | 2×Neutrik NL4 |
| FITTINGS | 12×M8 threaded inserts 1×mounting pole socket |
| Install Dim(HxWxD) | 692x470x443 mm |
| WEIHT | 31kg |
F15+ loudspeaker box design:
F15+ loudspeaker driver configuration:
HF:
LF:
♥ OEM /ODM orders are warmly welcome ,we can make the varied designs according to your need. Besides, we service alibaba trade assurance.
♥ All the goods are inspected before shipment, so we can ensure the best quality of products .
♥Free warranty service for one year ,within this period ,you can enjoy free maintenance service by warranty cards and invoice if a failure occurs under normal operation.
♥ If you have any problems,please feel free to let us know, by e-mail, telephone ,skype, WhatsApp or the others ,we will reply you as soon as we can.
