Single Core Heat Shrinkable Terminations

Single Core Heat Shrinkable Terminations thumbnail-1
Single Core Heat Shrinkable Terminations thumbnail-2
Single Core Heat Shrinkable Terminations photo-1
Single Core Heat Shrinkable Terminations photo-2
Negotiable MOQ: 100 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SUNBOW
Model Number:
SB-HSTJ02
Contact Supplier Request Quote Chat Now
Shenzhen Sunbow Insulation Materials Mfg. Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SUNBOW
Model Number SB-HSTJ02
Type Insulation Sleeving
Material PE
Application High Voltage



Single Core Heat Shrinkable Terminations



Single Core Heat Shrinkable Terminations



DESCRIPTION



l  Heat shrink terminations and straight joints have 3 kinds of voltage: 1KV, 10KV, 35KV and they are widely used for       the voltages separately under 1KV, 8.7~15KV and 25~35KV.



l  Heat shrink terminations and straight joints can be used for 1 core, 2 cores, 3 cores, 4 cores and 5 cores.



l  Heat shrink terminations and straight joints can be used for indoor, outdoor and joints.



l  Heat shrink terminations and straight joints have 2 kinds separately be used for XLPE cable and PILC cable.



CHARACTERISTICS



l  High mechanical strength



l  Shrink swiftly, no cracks



l  Heat shrink accessories can thwart burn



l  Wide cross section range



l  Increased UV and weathering stability



l  Unlimited shelf life and allows reenergizing



DIMENSION (HEAT SHRINK TERMINATION)



Voltage

Cores

Description

Cable Size

Model Number

18/30KV (36)

1

Indoor

50mm2

18/30kVRSNY-1-1

70-120mm2

18/30kVRSNY-1-2

150-240mm2

18/30kVRSNY-1-3

1

Outdoor

50mm2

18/30kVRSWY-1-1

70-120mm2

18/30kVRSWY-1-2

150-240mm2

18/30kVRSWY-1-3

12/20kV (24)

1

Indoor

35-50mm2

12/20kVRSNY-1-1

70-120mm2

12/20kVRSNY-1-2

150-240mm2

12/20kVRSNY-1-3

300mm2

12/20kVRSNY-1-4

1

Outdoor

35-50mm2

12/20kVRSWY-1-1

70-120mm2

12/20kVRSWY-1-2

150-240mm2

12/20kVRSWY-1-3

300mm2

12/20kVRSWY-1-4

8.7/15kV(17.5)

1

Indoor

25-50mm2

8.7/15kVRSNY-1-1

70-120mm2

8.7/15kVRSNY-1-2

150-240mm2

8.7/15kVRSNY-1-3

300mm2

8.7/15kVRSNY-1-4

1

Outdoor

25-50mm2

8.7/15kVRSWY-1-1

70-120mm2

8.7/15kVRSWY-1-2

150-240mm2

8.7/15kVRSWY-1-3

300mm2

8.7/15kVRSWY-1-4

6.35/11kV(12)

1

Indoor

25-50mm2

6.35/11kVRSNY-1-1

70-120mm2

6.35/11kVRSNY-1-2

150-240mm2

6.35/11kVRSNY-1-3

300-400mm2

6.35/11kVRSNY-1-4

1

Outdoor

25-50mm2

6.35/11kVRSWY-1-1

70-120mm2

6.35/11kVRSWY-1-2

150-240mm2

6.35/11kVRSWY-1-3

300-400mm2

6.35/11kVRSWY-1-4

18/30kV (36)

3

Indoor

50mm2

18/30kVRSNY-3-1

70-120mm2

18/30kVRSNY-3-2

150-240mm2

18/30kVRSNY-3-3

3

Outdoor

50mm2

18/30kVRSWY-3-1

70-120mm2

18/30kVRSWY-3-2

150-240mm2

18/30kVRSWY-3-3

12/20kV (24)

3

Indoor

35-50mm2

12/20kVRSNY-3-1

70-120mm2

12/20kVRSNY-3-2

150-240mm2

12/20kVRSNY-3-3

300mm2

12/20kVRSNY-3-4

3

Outdoor

35-50mm2

12/20kVRSWY-3-1

70-120mm2

12/20kVRSWY-3-2

150-240mm2

12/20kVRSWY-3-3

300mm2

12/20kVRSWY-3-4

8.7/15kV (17.5)

3

Indoor

25-50mm2

8.7/15kVRSNY-3-1

70-120mm2

8.7/15kVRSNY-3-2

150-240mm2

8.7/15kVRSNY-3-3

300mm2

8.7/15kVRSNY-3-4

3

Outdoor

25-50mm2

8.7/15kVRSWY-3-1

70-120mm2

8.7/15kVRSWY-3-2

150-240mm2

8.7/15kVRSWY-3-3

300mm2

8.7/15kVRSWY-3-4

6.35/11kV (12)

3

Indoor

25-50mm2

6.35/11kVRSNY-3-1

70-120mm2

6.35/11kVRSNY-3-2

150-240mm2

6.35/11kVRSNY-3-3

300-400mm2

6.35/11kVRSNY-3-4

3

Outdoor

25-50mm2

6.35/11kVRSWY-3-1

70-120mm2

6.35/11kVRSWY-3-2

150-240mm2

6.35/11kVRSWY-3-3

300-400mm2

6.35/11kVRSWY-3-4


DIMENSION (HEAT SHRINK JOINTS)

Voltage

Cores

Cable Size

Model Number

18/30kV (36)

1

50mm2

18/30kVRSJY-1-1

70-120mm2

18/30kVRSJY-1-2

150-240mm2

18/30kVRSJY-1-3

3

50mm2

18/30kVRSJY-3-1

70-120mm2

18/30kVRSJY-3-2

150-240mm2

18/30kVRSJY-3-3

12/20kV (24)

1

35-50mm2

12/20kVRSJY-1-1

70-120mm2

12/20kVRSJY-1-2

150-240mm2

12/20kVRSJY-1-3

300mm2

12/20kVRSJY-1-4

3

35-50mm2

12/20kVRSJY-3-1

70-120mm2

12/20kVRSJY-3-2

150-240mm2

12/20kVRSJY-3-3

300mm2

12/20kVRSJY-3-4

8.7/15kV (17.5)

1

25-50mm2

8.7/15kVRSJY-1-1

70-120mm2

8.7/15kVRSJY-1-2

150-240mm2

8.7/15kVRSJY-1-3

300mm2

8.7/15kVRSJY-1-4

3

25-50mm2

8.7/15kVRSJY-3-1

70-120mm2

8.7/15kVRSJY-3-2

150-240mm2

8.7/15kVRSJY-3-3

300mm2

8.7/15kVRSJY-3-4

6.35/11kV (12)

1

25-50mm2

6.35/11kVRSJY-1-1

70-120mm2

6.35/11kVRSJY-1-2

150-240mm2

6.35/11kVRSJY-1-3

300-400mm2

6.35/11kVRSJY-1-4

3

25-50mm2

6.35/11kVRSJY-3-1

70-120mm2

6.35/11kVRSJY-3-2

150-240mm2

6.35/11kVRSJY-3-3

300-400mm2

6.35/11kVRSJY-3-4
