GLORYSTAR Resin Buttons Laser Marking Machine with CE, SGS,ISO

Specifications

1.resin buttons laser marking machine
2.High speed, high precise, low cost
3.Marking non-metal materials, rubber,plastic,Acry

GLORYSTAR resin buttons laser marking machine with CE, SGS,ISO



AGENT/DEALER WANTED, WELOMCE YOU JOIN IN.
Web:

Credit first, Quality first, Your satisfaction, Our passion.



Technical Data:

Model	CMT-30/CMT-60/CMT-100
Max. Average Power	30W/60W/100W
Wave Length	10.64um
Output Stability(8h)	± 5%/ ± 10%
Marking Area	110mmX110mm or 175mmX175mm (30W)
	175mmX175mm or 300mmX300mm (60W)
	175mmX175mm or 300mmX300mm (100W)
Output Power	10% ~100% continuous adjustable
Output Frequency	0KHZ~200Khz continuous adjustable
Marking Speed	≤3m/s
Marking Depth	≤8mm
Min. Character Size	0.6mm
Min. Line Width	0.12mm
Repetition Accuracy	±0.01mm
Operating System	WindowsXP/2000/98
Cooling System	Air cooling(10W/30W/60W)
	Water cooling(100W)
Environment Temperature	10°C~30°C
Humidity	45%-75%
Power Voltage	220V/50Hz/60Hz/10A
Overall Power Consumption	1.5KW (30W)
	2.0KW (60W)
	4.0KW (100W)
Marking Graph	User-defined character, CAD data
Supported Format	BMP,JPG,PNG,TIF,PCX,TAG,IOO,GIF,PLT



Advantages:

1. Adopting USA CO2 Radio Frequency metal laser generator, and high-speed scanner imported originally from USA.

2. This series laser machine obtains high speed and high accuracy with laser focusing solution in the rear part.

3. By using Window interface, the software of the machine is compatible with different output formats, CorelDraw, AutoCAD, Photoshop, Illustrator, etc.

4. The power, which controlled by software is continually adjusted.

5. No consumable material existing, the fabrication cost is lower.

6. It has high effectiveness with large marking area and fine marking spots.

7. The engraving depth can be controlled and adjusted for purpose, suitable for all kinds of products.



Applicable industry:

Widely apply to different kinds of consumer commodities, food beverage packaging, medicine packing, architecture ceramic,
costume and accessories, leather and wool, gift and crafts, nameplates, jeans, furniture, etc.



Materials:

Non-metal materials, such as paper, leather, cloth, organic glass, resin, acrylic, woolens, plastic, rubber, ceramic, crystal, jade, bamboo and wood crafts.
