PJ110-10 Motorized Goniometer Stage
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Beijing, China
Brand Name:
PDV
Model Number:
PJ110-10
Payment & Shipping
Payment Methods:
Port of Shipment:
Beijing
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Beijing, China
Brand Name
PDV
Model Number
PJ110-10
Structure Specifications
1 Item Number: PJ110-10
2 Rotation Range: ±10°
3 Platform: 65mm × 65mm
4 Drive Mechanism: Worm Gear
5 Travel Guide: Crossed Roller Bearing
6 Worm Gear Ratio: 352 : 1
7 Height of Rotation Stage: 75 mm±0.2 mm
8 Stepper Motor (1.8°): 42BYG - Stepping Motor with 2-Phases & 1.8° of Step Angle
9 Material – Finish: Aluminum Alloy - Black-Anodized
10 Load Capacity: 5Kgs
11 Weight: 0.75kgs
Accuracy Specifications
1 Design Resolution: ≈0.005°≈18″(Non-MS Driver); ≈1″(20MS Drive)
2 Rotation Center Deflection Accuracy: 0.03 mm
3 Max Velocity: 7°/sec
4 Repeatability: ±4”
5 Absolute Accuracy: ±9”
6 Backlash: ±4”
7 Lost Motion: 3″
