Ideal Design Power Stacker--CLT10AC Series

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Shanghai, China
Brand Name	Cheuk's	Model Number	CLT10AC series
Dimension(LWH)	18008502040mm	Certification	CE
Warranty	1 year	After-sales Service Provided	No overseas service provided

Product Description

The product intro of electric stacker CLT10AC series

1.Compact structure, good looking

2.Hydrappp pump station from Italy,more stable when lifting goods.The power unit joins DC machine,wheel pump, valve plate and pipeline together;small,reliable,stable,low noise,save energy and environmental-friendly

3.Curtis controller system,nimble,easy to operate,reliable,regenerative braking,plug braking and stepless speed regulating functions

4.Large capacity battery,long lasting power,easy to charge

The specification of electric stacker CLT10AC series

1KG=2.2LB 1INCH=25.4MM

Identification	1.1	Model	Unit	CLT1025AC	CLT1030AC	CLT1033AC
	1.2	Power:electric(battery),diesel,petrol,natural gas		electric
	1.3	Manner of operation:(hand,pedestran,seated, standing sorting-picker)		standing
	1.4	Load Capacity	Q(Kg)	1000	1000	1000
	1.5	Load Centre distance	c(mm)	500	500	500
	1.6	Wheelbase	Y(mm)	1419	1419	1419
Weight	2.1	Weight	kg	1100	1200	1300
Wheels Types	3.1	Tyres(rubber, highelastomer,pneumatic, polyurethane		PU wheel
	3.2	Front wheel size		78	78	78
	3.3	Rear wheel size		124	124	124
	3.4	Drive wheel		230	230	230
	3.5	Track width(front)drive side	b10(mm)	390	390	390
	3.6	Track width(rear)load side	b11(mm)	608	608	608
Dimensions	4.1	Closed mast height	h1(mm)	1790	2040	2190
	4.2	Lift height	h3(mm)	90~2500	90~3000	90~3300
	4.3	Overall length	l1(mm)	1800	1800	1800
	4.4	Overall width	b1Ib2(mm)	850	850	850
	4.5	Length between fork backrest and vehicle body	Slell(mm)	1150	1150	1150
	4.6	Overall fork width	b5(mm)	560	560	560
	4.7	Turning radius	Wa(mm)	1690	1690	1690
Performance	5.1	Speed Load/unload	Km/h	5.3/6.0	5.3/6.0	5.3/6.0
	5.2	Lifting speed Load/unload	Km/h	70	70	70
	5.3	Lowering speed Load/unload	Km/h	100	100	100
	5.4	Brakes	mm	1	1	1
Motor	6.1	Drive motor	kW	1.6	1.6	1.6
	6.2	Lifting motor	kW	22	22	22
	6.3	Battery voltage,normal capacity	V/Ah	24/210	24/210	24/210
	6.4	Battery weight	Kg	210	210	210
	6.5	Battery dimensions	mm	650x200x540

Company Information

Shanghai Cheuk's Logistics Technology Co., Ltd.,which is subordinate to Cheuksgroup, is specializing in the developing, manufacturing and marketing of logistics, lifting and hydraulic machinery. We have abundant product line, forklift truck, pallet truck, stacker, table lift, tail gate, tow trackor, aerial work platform,plastic hand truck, hydraulic tools and so on.

Our sales and network covers all over the world, also R&D center in Germany and America. We keep a really good relationship with our abroad partners. We based in China, supply you with our standard products of reliable quality, reasonable price. Also,the OEM service is available according to your requirements. Give us an opportunity, we will "Lifting your future"!
