Home > Manufacturing & Processing Machinery > Lifting Equipment > Stacker & Reclaimer > Hand Stacker--HSM Series

Hand Stacker--HSM Series

Name: Hand Stacker--HSM Series
Brand: Cheuk's
SKU: 100558673
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Place of Origin:

Shanghai, China

Brand Name:

Cheuk's

Contact Supplier Request Quote Chat Now

Shanghai Cheuk's Logistics Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Place of Origin Shanghai, China

Brand Name Cheuk's

Model Number HSM series

Dimension(L*W*H) 1200*900*1900 mm

Certification CE

Warranty 1 year

After-sales Service Provided No overseas service provided

The product name: Hand Stacker--HSMseries

The specification of hand Stacker--HSM series

Stronger motor,Larger battery 12Ah,Low voltage protection.
A range of highly manoeuvrable,lightweight lifts,designed to take the strain out any liftingjob from ground level to over
shoulder height.
Ideal for use in narrow aisles and confined spaces.
Perfect for all applications frompharmaceutical to catering,from packing line to food processing,from warehouse to office,
kitchens,laboratories,retail outlets,etc...
Manual models:Operated via a manual hand winch.
Auto brake system prevents uncontrolled lowering.
Electric models:Automatic electronic overload protection system ensures safety.
Maintenance free and sealed batteries,automatic charger.
Quick change attachment options available.
Conforms to EN1757,CE marked.

1kg=2.2lb 1ICH=25.4MM

Model		HSM100	HSM200	HSE100A	HSE150A
Type		Manual		Electric
Capacity	(kg)	100	200	100	150
Load Centre	(mm)	235	235	235	235
Max.Fork height	(mm)	1500	1500	1700	1500
Min.Fork height	(mm)	130	130	130	130
Platform Size	(mm)	470×600	470×600	470×600	470×600
Overall	(mm)	840×600×1830	870×600×1920	870×600×1990	870×600×1790
Load Wheel	(mm)	75	75	75	75
Steeing Wheel	(mm)	125	125	125	125
Batter,Service Free		—	—	24/12Ah	24/12Ah
Net Weight	(kg)	50	60	66	63

About Shanghai Cheuk's Logistics Technology Co.,Ltd.

Shanghai Cheuk's Logistics Technology Co.,Ltd.is subordinated to Shanghai Cheuks Group company, located in the modern and international city, Shanghai, focuses on R&D, manufacturing, selling and service of material handling equipments and construction machinery.

Cheuk's provides 15 series products with more than seven hundred models, including aerial work platform, pallet truck, stacker, forklift truck, tow tractor, hand truck, drum picker,etc. Cheuk's pays attention to all the links of production by supervising in raw material purchase, the working procedure and quality control test. Moreover, Cheuk's is granted ISO9001, ISO14001 and ISO18001 authentication certificate. Most of the products are granted CE or GS certificates by TÜV Rheinland Group.

With high quality, best price of product and good service, Cheuk's becomes more and more popular in domestic market as well as international market. In addition, Cheuk's products have been widely used in no less than a hundred countries in various areas, including construction of road, railway, bridge, airport, underground, wharf, public works, communication system, shipbuilding, advertisement, supermarket, factory and so on. Cheuk's gets a high reputation in its area since customers have great experience by using our products.

Cheuk's devotes to developing highly innovative products, professional services and creative solutions for our customers all over the world.

Give us an opportunity, we will lifting your future
