Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Excavator > HK300SD Amphibious Excavator
HK300SD Amphibious Excavator
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Anhui, China
Brand Name:
Heking
Model Number:
HK300SD
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Anhui, China
Brand Name
Heking
Model Number
HK300SD
Condition
New
Moving Type
Crawler Excavator
Operating Weight
30000
Bucket capacity
0.9
Maximum Digging Height
10514
Maximum Digging Depth
5766
Machine Weight
30000
Max Digging Radius
9925
Specifications
work on swamp and soft areas1.dredging2.cleaning fish pond & managing waste ponds3.wetland reclamation & developmentwork on swamp and soft areas
1.dredging
2.cleaning fish pond & managing waste ponds
3.wetland reclamation & development
4. Powerful ISUZU engine
| HK300SD | |
| Specification | |
| Operating weight | 30000kg |
| Standard bucket capacity | 0.9m³ |
| Boom length | 5680 |
| Arm length | 2912 |
| Chains | 3 |
| Engine: | |
| Model | Isuzu 6BG1 |
| Type | inter-cooled turbo |
| Power | 114kW/2100rpm |
| Max.torque | 629N m / 1600rpm |
| No.of cylindar | 6 |
| Displacement | 6.494L |
| Hydraulic system | |
| Main pump | |
| Type | Variable plunger pump |
| Max.displacement | 2X107cm3/r |
| Max.flow | 20L/min |
| Working pressure | 32Mpa |
| Hydraulic motor | |
| Slew motor | fixed plunger |
| Travel motor | variable plunger |
| Performance | |
| Slew speed | 11rpm |
| Min.slew radius | 3554mm |
| Max.travel speed high/low | 3.29/2.17km/h |
| Gradeability | 70% |
| Tracktive effort | 382.4kN |
| Max.digging force of bucket | 122.85kN |
| Max.digging force of arm | 97.64kN |
| Ground pressure | 0.14kg/cm2 |
| Oil tank capacity | |
| Fuel tank capacity | 376L |
| Hydraulic tank capacity | 219L |
| Item | |
| Length of pontoon | 8285 |
| Ground clearance of platform | 1936 |
| Overall height | 3759 |
| Boom transport height | 3379 |
| Overall length | 10747 |
| Rear swing radius | 2800 |
| Track gauge | 3950 |
| Overall width | 5742 |
| Width of pontoon | 1800 |
| Min.ground clearance | 1126 |
| Height of pontoon | 1652 |
| Width of upper structure | 2622 |
| Ground length | 5088 |
| Item | |
| Max.digging reach | 9925 |
| Max.digging reach on ground | 9556 |
| Max.digging depth | 5766 |
| Max.vertical digging depth | 5189 |
| Max.digging height | 10514 |
| Max.dumping height | 7748 |
| Min.front slewing radius | 3554 |
