Best Digital TX2200 Textile Roller Multicolor t Shirt Printing Machine

Best Digital TX2200 Textile Roller Multicolor t Shirt Printing Machine photo-1
Best Digital TX2200 Textile Roller Multicolor t Shirt Printing Machine photo-2
Best Digital TX2200 Textile Roller Multicolor t Shirt Printing Machine photo-3
Best Digital TX2200 Textile Roller Multicolor t Shirt Printing Machine photo-4
US$ 8,000 - 12,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Plate Type:
Other, roll to roll printer
Place of Origin:
China
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Plate Type Other, roll to roll printer
Place of Origin China
Brand Name TAIMES
Model Number TX2200
Usage Cloths Printer, Other, Cloths Printer, fabric /textile printer
Automatic Grade Automatic
Voltage 50Hz/60Hz
Gross Power 220V~(+10%)>15A,50Hz/60Hz
Dimensions(L*W*H) 360x100x127CM
Weight 605KG
Certification CE Certification
After-sales Service Provided Engineers available to service machinery overseas

Best digital TX2200 textile roller multicolor t shirt printing machine

Product Description
    Feature:

    Product:     Taimes digital textile printer tx2200

    Model:         Tx2204I- km1024i -14PL-4H

    Printing Quality:   1440dpi

    Draft Mode:     360X720dpi - 2pass @ 110sqm/h

    Production Mode: 360X1080dpi - 3pass @ 85sqm/h

    Quality Mode:   360X1440dpi - 4pass @ 65sqm/h

The advantages of the Tx2200 printer:

No.1  Adopt Konica company the latest 1024i water based print head, Its unique high speed technology can achieve higher productivity, higher nozzle density makes the printings more accurate and colour more gorgeous, the ink optimization design achieved the higher printing stability, and this print head has been recognized as a green environmental protection product.



Best digital TX2200 textile roller multicolor t shirt printing machine



NO.2  400W super power Panasonic AC servo motor system, for the machine runs provided a powerful impetus.

NO.3 The special concave printing platform design, makes the osmotic inks through the  fabric in printing can be collected very well, avoid wasting time for cleanning the dirty fabric, and greatly improved the production efficiency for you.

NO.4 Specially used the plastic press roller, which effectively eliminate the phenomenon to be scratched and scrape the thread for the materials, and let the printing running smoothly.



Best digital TX2200 textile roller multicolor t shirt printing machine

NO.5  The liquid level display of the main ink bottle designed in the side of the printing platform, used the people’s familiar colour sign - red, yellow and green, make the ink amount is clear at a glance, very convenient to operate.

NO.6 Equipped with moisturizing systems on print head plate, shall make sure the inks will not be dry, then still print brilliantly even under hot environment.



Best digital TX2200 textile roller multicolor t shirt printing machine

NO.7  Equipped with the outside suction system, makes the printings dry fast, achieved the

synchronization effect between printing and take up the cloth, and greatly improved the

NO.8  Elaborate more cross rod for the take up and feeding system, could meet more printing materials, also makes the materials take up and feed freely work efficiency.



Best digital TX2200 textile roller multicolor t shirt printing machine



NO.9 The TX2204I printer is used to work together with the Heating machine, so that



      makes the inks on the fabric show more obvious and gorgeous colour!



Best digital TX2200 textile roller multicolor t shirt printing machine

         Item

 Specification

         Model

TAIMES TX2200 Textile Digital Printer

        Print head

KONICA 1024I Printhead

       Number of Printhead

4

      Maximum Print Width

2.2M (88inch)

       Print Speed

Colorized

100m2/hr

           Color

CMYK

          Media

Sublimation Fabric

   Maximum Print Quality

1440dpi

   Auto Media System

Equippe



Auto Cleaning System

Positive Pressure Cleaning

Spray in Idel Function

        Image Format

Bitmap, TIFF, Quark Xpress, JPGEG, AI, EPS, PDF

        Color Management

Superior ICC Profile

      Work Flow



       RIP and Print at the same time/Print after RIP

   Print Interface

USB2.0

        Ink Type

Sublimation Ink

         Software

Photo Print, Inwear Edition

        Work Station

Microsoft Windows 2000 or Windows XP. Windows7

       Operating Environment

220V~(+10%)>15A,50Hz/60Hz

     Machine Dimension

360x100x127CM

    Wooden Case Dimension

372x110x144CM

Payment


Payment terms: We usually accept T/T, Western Union, Paypal, Money Gram, L/C.



Profession technical Service & guidance of other related products, not only the items you purchased from us.



We provide 24-hours ofpre-sale, saling & after-sale service. Quick inquiry responses that satisfy customer needs

Shipping Info

We will send the item by SEAetc. Express.

There are no shipments on weekend and public holidays.

Please let me know your daytime contact phone numberzip code and deliver address before shipping.

Best digital TX2200 textile roller multicolor t shirt printing machine

Our Service

Instant online support service



Besides the door to door service, TAIMES also provide support on telephone and online service etc to make sure that our experienced service team can solve the technical problems timely even we are not in your side.

Best digital TX2200 textile roller multicolor t shirt printing machine



Well experienced service team



Best digital TX2200 textile roller multicolor t shirt printing machineBest digital TX2200 textile roller multicolor t shirt printing machine
