Late Model Standard Digital Clamp Meter
Negotiable
MOQ: 30 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Huamao
Model Number:
HM-LE060
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Zhejiang, China
Brand Name
Huamao
Model Number
HM-LE060
Specifications
Late model Standard Digital Clamp MeterLate model Standard Digital Clamp Meter
Basic Function |
Measurement range |
Basic Accuracy |
VC9801A+ | ||
DC Voltage |
200mV/2V/20V/200V/1000V |
±(0.5%+1) |
AC Voltage |
2V/20V/200V/750V |
±(0.8%+3) |
200mV/2V/20V/200V/1000V |
||
DC current |
200µA/2mA/20mA/200mA/20A |
±(1%+3) |
2mV/20mA/20A |
||
AC current |
200µA/2mA/20mA/200mA/20A |
±(1%+3) |
2mA/200mA/20A/200mA/20A |
||
Resistance |
200Ω/2kΩ/20kΩ/200kΩ/20MΩ/200MΩ |
±(0.8%+3) |
|
Capacitance
|
20nF/200nF/2µF/20µF/200µF |
±(0.8%+3) |
20nF/200nF/20µF/200µF |
Special function |
VC9801A+ |
Diode test |
√ |
Triode test |
√ |
Continuity buzzer |
√ |
Low Voltage indicate |
√ |
Data hold |
√ |
Backlight |
√ |
Maximum display |
1999 |
LCD Size |
70*50mm |
