Kirisun TP660 DMR Double Capacity Repeater Mode Portable Radio From China

Kirisun TP660 DMR Double Capacity Repeater Mode Portable Radio From China thumbnail-1
Kirisun TP660 DMR Double Capacity Repeater Mode Portable Radio From China photo-1
Negotiable MOQ: 2 Units (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
KIRISUN
Model Number:
TT660
Contact Supplier Request Quote Chat Now
Guangzhou Etmy Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name KIRISUN
Model Number TT660
Type Handheld
Dimensions 54mm*122mm*37mm
Frequency Range 400~470MHz 136-174MHz
Storage Channel 1000
Talk Range 5-8km

Kirisun TP660 DMR Double Capacity Repeater Mode Portable Radio



Product Description

Kirisun TP660 DMR Double Capacity Repeater Mode Portable radio from china



Rugged Design
TP660 is strictly designed to meet IP67 and MIL-810C/D/E/F/G standard, ensuring good performance in potentially harsh environments such as harbors, manufacturing plants, petrochemical factory and construction sites.

Durable Battery
Two-time slot transmission reduces transmit time in half and thus increases talk time longevity. .2000mAh battery supplied in standard package ensures at least 14 continuous working hours in analog mode and 16 hours in digital mode.

Improved Audio Quality
Digital error-correction technology rejects noise and static, providing consistent audio quality throughout the coverage area and in challenging low lying areas..
AMBE+2TM vocoder further improves speech communication. 1.6W audio output and a 40mm diameter powerful speaker ensure louder and crisper voice communication.

Double Capacity Repeater Mode
TP660 can work with a single repeater to achieve twice the traffic capacity without relicensing or rebanding, meaning two voice communications or one voice communication and one data transmission can transmit at the same time in one channel.

Analog/Digital Mode
TP660 can operate both in analog and digital mode by channel switching or mixed mode scanning. TP660 can be used on the existing analog system, and when your budget allows, transitioning to digital at your own pace.

Versatile Services
TP660 provides versatile services including individual call, all call, group call, emergency call, radio enable & disable, remote monitor, radio check, call alert, facilitating high-efficient communication and management.

Text Message
When it is not convenient to have voice communication, text message offers a quiet communication choice. You can choose one of the maximum 50 preset messages to initiate a quick transmission or write a free-form message by keypad.

Basic Encryption
The 16-bit digital encryption technology ensures only the intended person can hear the communication.
One Touch Access
Support one touch access to send a digital call or a message, providing a quick way to send a call or a message under emergency situation.


DTMF Encode and Decode

Supports DTMF encode and decode in analog mode, providing better compatibility with existing analog radio system.

MOQ

2-500PCS

OEM/ODM

ACCEPTED

DELIEVERY TIME

5-7 DYAS (SAMPLE); 20-25 DAYS (MASS)

CERTIFICATE

CE/FCC/ROHS

SAMPLE SUPPORT

SAMPLE IS AVAILABLE, CHARGING COST WILL BE SPECIAL

TP660

Frequency Range

400~470MHz  136-174MHz

Channel Capacity

1000

Channel Spacing

12.5KHz/25KHz

Operating Voltage

7.5V DC ±20%

Battery

2000mAh Li-ion (Standard)

Dimension

54mm×122mm×37mm

Weight(with battery and antenna)

300g

Transmitter

Frequency Stability

±2.5 ppm

Power Output

1W/4W(UHF)  1W/5W(VHF)

Modulation Limiting

2.5kHz12.5KHz, 5kHz25kHz

FM Hum and Noise

-40dB12.5kHz   -45dB25kHz

Conducted/Radiated Emission

-36dBm<1GHz, -30dBm>1GHz

Adjacent Channel Power

-60dB12.5KHz, -70dB25KHz

Audio Response

+1dB,-3dB

Audio Distortion

3%

4FSK Digital Modulation

12.5KHz(data only):7K60FXD
12.5KHz(data+voice):7K60FXE

Digital Protocal

ETSI TS 102 361-1, -2, -3

Receiver

Frequency Stability

±2.5 ppm

Analog Sensitivity

0.35μV /-116dBm(12 dB SINAD)

Digital Sensitivity

0.22μV /-120dBm

Intermodulation

TIA603C:70dB   ETSI:65dB

Adjacent Channel Selectivity

ETSI: 60dB12.5kHz,70dB25kHz

Spurious Response Rejection

TIA603C:75dB   ETSI:70dB

Rated Audio Power

1.5W±0.1W

Rated Audio Distortion

3% (Typical)

Hum and Noise

-40dB12.5kHz   -45dB25kHz

Audio Response

+1dB,-3dB

Conducted Spurious Emission

-57dBm < 1GHz,-47dBm > 1GHz

Environmental Specifications

Operating Temperature

-30℃~+60℃

Storage Temperature

-40℃~+85℃

Thermal Shock

MIL-STD-810 C/D/E/F/G

Humidity

MIL-STD-810 C/D/E/F/G

ESD

IEC 61000-4-2(level 4)

Dustproof & Waterproof

IP67
