Features
1) Output:3W
2) Frequency Range: 136.00-174.00 MHz
400.00-470.00 MHz
3) PC or Manual Program
4) BCL Function
5) Battery Saving
6) DTMF Code
7) Dual Band, Dual Display and Dual Standby
8) Emergency Alarm
9) 50 CTCSS and 104 DCS Codes
10) Keypad Tone Setting
11) VOX Function
12) High &Low Power Switchover
13) Priory Scanning Function
14) Wide/Narrow Band Selection
15) Time-out Timer (TOT)
16) 1750 KHz Relay Forwarding Confirmed
17) FM Radio Function
18) Different Frequency Setting
19) Dimension: 99x55x30mm
20) Packing Details: 50 Units/CTN, Carton Size: 51x45x71cm
N.W:22.5KGS, G. W: 23.5KGS
Unity Section:
Frequency Range: |
136.00-174.00 MHz |
400.00- 470.00MHz | |
Storage Channel |
99 |
Step Frequency |
2.5/5/6.25/10/12.5/20/25KHz |
Rated voltage |
DC 3.7V |
Battery Capacity |
H-1500 mAh |
Battery Life |
About 10 Hours |
Frequency Stability |
±2.5ppm |
Work Temperature |
-20 ℃to +60℃ |
Frequency Combination |
PLL frequency synthesis |
Antenna Impedance |
50 Ω |
Wok Mode |
Same Frequency simplex Operation or Different Frequency simplex Operation |
Dimension |
99x55x 30 mm (Excluded Antenna) |
Transmitter
Output Power |
3W |
Modulation Mode(W/N Band) |
FM (F3E) |
Maximum Frequency Deviation (W/N Band) |
<5KHz(W), <2.5KHz(N) |
Spurious Power |
≤7.5 µW |
Adjacent channel power |
65dB (W) ,55dB (N) |
Spurious Radiation |
<-60 dB |
Audio Distortion |
<5 % |
SNR |
45dB(W), 40dB(N) |
CTSCC/DCS Frequency Deviation(W/N Band) |
0.7±0.1KHz (W), 0.4±0.1KHz (N) |
Modulation Sensitivity |
8-12mV |
Transmitting Current |
≤1500mA |
Receiver
Sensitivity |
<0.20 µ V (12dB SINAD) |
Audio Power |
1 W |
Inter modulation Interference Resistance |
≥65dB (W), ≥55dB (N) |
Adjacent channel Sensitivity (W/N Band) |
≥65dB (W), ≥55dB (N) |
Audio Distortion |
5 % |
Receiving Current |
≤ 400m A |
Shipping & Payment:
MOQ: |
1pc (small or trial order), 100pcs for bulk order |
Packaging: |
battery in Polybag and box packing, 100pcs /carton |
Loading port: |
HongKong or Guangzhou |
Delivery date: |
Within 2-5 days after payment confirmed |
Terms of Payment: |
T/T, Western Union, Paypal, Escrow |
Warranty: |
Six month |
Delivery Time and Way:
|
Hong Kong Post |
DHL,UPS, |
Air |
Sea |
Sample Order Under 2KG |
10-20 working days |
5-7 working days |
Inapplicability |
Inapplicability |
Other Order More Than 2KG |
Inapplicability |
5-7 working days |
7-10 working days |
15-25 working days |
