Newst fm Radio for Bao Feng Mobile Phone BF-5688 Two Way Radio

Newst fm Radio for Bao Feng Mobile Phone BF-5688 Two Way Radio thumbnail-1
Newst fm Radio for Bao Feng Mobile Phone BF-5688 Two Way Radio thumbnail-2
Newst fm Radio for Bao Feng Mobile Phone BF-5688 Two Way Radio thumbnail-3
Newst fm Radio for Bao Feng Mobile Phone BF-5688 Two Way Radio thumbnail-4
Newst fm Radio for Bao Feng Mobile Phone BF-5688 Two Way Radio thumbnail-5
Newst fm Radio for Bao Feng Mobile Phone BF-5688 Two Way Radio photo-1
Newst fm Radio for Bao Feng Mobile Phone BF-5688 Two Way Radio photo-2
Newst fm Radio for Bao Feng Mobile Phone BF-5688 Two Way Radio photo-3
Newst fm Radio for Bao Feng Mobile Phone BF-5688 Two Way Radio photo-4
Newst fm Radio for Bao Feng Mobile Phone BF-5688 Two Way Radio photo-5
US$ 15.6 - 34.5 MOQ: 1 Acre
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Baofeng
Model Number:
BF-5688
Contact Supplier Request Quote Chat Now
Guangzhou Etmy Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name Baofeng
Model Number BF-5688
Type Handheld
Dimensions 129x61x 35 mm (Excluded Antenna)
Frequency Range 400.00- 470.00MHz, 400.00-470.00 MHz
Storage Channel 16, 16
Talk Range 5-10KM
Product Description

Features



1)       Output: 5W



2)       Frequency Range: 400.00-470.00 MHz



3)       16 Channels



4)       PC Program



5)       FM Radio Function



6)       Voice Prompt



7)       39 CTCSS and 83 DCS Codes



8)       Battery Saving



9)       VOX (Voice Operated Transmitting) Function



10)   Busy Channel Lock



11)   Low Battery Warning



12)   Over Voltage or Low Voltage Protection



13)   Emergency Alarm



14)   Channel Monitor



15)    TOT (Time-out Timer)



16)   Chinese/English Switch



17)   High &Low Power Switchover



18)   Noise Reduction



19)   Scrambler Function



20)   Dimension: 129x61x35 mm



21)   Packing Details: 50 Units/CTN,  Carton Size: 51x45x71 cm



                   N.W: 22.5 KGS   G.W: 23.5 KGS





Unity Section:



Frequency Range:

400.00- 470.00MHz

Storage Channel

16

Step Frequency

12.5/25KHz

Rated voltage

DC 7.4 V

Battery Capacity

H-1500 mAh

Battery Life

About 10 Hours

Frequency Stability

±2.5ppm

Work Temperature

-20 ℃ to +60℃

Frequency Combination

PLL frequency synthesis

Antenna Impedance

50 Ω

Wok Mode

Same Frequency  simplex Operation or

 Different Frequency  simplex Operation

Dimension

129x61x 35 mm (Excluded Antenna)



                                                                  Transmitter



Output Power

5W

Modulation Mode(W/N Band)

FM (F3E)

Maximum Frequency Deviation (W/N Band)

<5KHz(W), <2.5KHz(N)

Spurious Power

≤7.5 µW

Adjacent channel power

65dB (W) ,55dB (N)

Spurious Radiation

<-60 dB

Audio Distortion

<5 %

SNR

-52dB(W), -48dB(N)

CTSCC/DCS Frequency Deviation(W/N Band)

0.7±0.1KHz (W), 0.4±0.1KHz (N)

Modulation Sensitivity

8-12mV

Transmitting Current

≤1500mA



Receiver



Sensitivity

<0.20 µ V (12dB  SINAD)

Audio Power

1 W

Inter modulation Interference Resistance

≥65dB (W), ≥55dB (N)

Adjacent channel Sensitivity (W/N Band)

≥65dB (W), ≥55dB (N)

Audio Distortion

5 %

Receiving Current

≤ 400m A









 Newst fm radio for bao feng mobile phone BF-5688 two way radioNewst fm radio for bao feng mobile phone BF-5688 two way radioNewst fm radio for bao feng mobile phone BF-5688 two way radio
