47 Inch Digital Signage Touch Screen Kiosk Machine

Chinese/English OSD menu, easy to operate

Aluminium alloy frame, ultra-thin design, easy to use, fashionable appearance

Adopt the latest 3D digital decoding and image noise reduction technology

Automatic elimination of ghosting function, protecting long-term use of LCD screen

A variety of digital images to correct circuit, minimize image distortion

16.7M color depth, image is more natural and smooth

6ms fast response time, no shadow or tail in picture

Built-in power supply, low consumption, longer life time

Equipped with sensitive infrared receiver, can adjust the parameters of the display via remote control

LCD

Model No.

XS-4700HD-TW

Panel

47” LG panel

Display Ratio

16:9

Resolution

1920(H)x1080(V)

Contrast

3000:1

Response Time

6ms

Brightness

350cd/m2

Viewing Angle

178/178(H/V)

Backlight Life

30000H

Color

16.7M

PC

Mainboard

Intel

Graphics

Integrated graphics

CPU

Intel i3 dual-core 1.7GHZ

RAM

Kingston 4G  DDR3   1333MHZ

HDD

128G SSD

Built-in Network

RTL  8101C

USB

USB2.0x2  USB3.0x2

Other Interface

RJ45, Audio, Mic

HDMI Output

x1

VGA Output

x1

TV

HDMI1/HDMI2 dual input

Yes

VGA Input

Yes

AV Audio Output

L/R

AV Video Output

Yes

AV Video Input

Yes

AV Audio Input

L/R

TV Cable Interface

Yes

USB

Support video and picture play from U disk

Headphone Output

Yes

5+5W Speaker

5+5W

Touchscreen

Touch Points

4, 6 points

Resolution

4096x4096

Response Speed

>10ms

Scan Speed

60/S

Input Method

Finger touch or other opaque medium

Luminousness

>98%

Min Touch Diameter

5mm

Touch Times

Unlimited

Persistence

More than 60 million times single-touch

Surface Hardness

Mohs 7

Working Environment

Working Temperature

0℃-40℃

Storage Temperature

-20℃-60℃

Storage Humidity

10%-75%RH

Working Humidity

20%-80%RH

Others

Overall Dimension

1110(W)x654(H)x60(D)mm

Power Consumption

<=180W

Power Supply

AC110-240V 50/60HZ
