Specifications
0.1~8mm Square Expanded Metal Sheet1.Own personal factory
2style :raised and flattend
3.Perfect quality but low price
0.1~8mm Square Expanded Metal Sheet
Specifications
We have filter expanded mesh, Industrial expanded metal, decorating metal mesh, mini-opening expanded mesh, security fence expanded.
Expanded SheetAdvantages
- Quality Certification:ISO9000-2001, High-qulity products
- Enterprise Corporation, Low-cost due to Low price
- 25-years history of producing, Reliability is our strong point
Material:low carbon steel wire, stainless steel plate, copper plate, aluminum plate, Al-Mg alloy plate, iron plate.
Process:punched to mesh
Uses:used in road,railway,resident,machines,electical equipment for protecting and isolating
Features:aesthetic appearance,corrosion resistance,high safety factor and be used in lots of industries for fencing
Surface treament:Galvanized and PE/PVC coated.Galvanized including Hot-dip galvanized and electic Galvanized;PE coated including powder coated and PE coated.
Colors:white,green,blue,red,yellow etc.
| Specification | ||||||
| Mesh (mm) | Mesh Sheet | |||||
| Thickness | Width | Length | Strip | Width(m) | Length(m) | Weight (kg/m2) |
| 0.5 | 2.5 | 4.5 | 0.5 | 0.5 | 1 | 1.8 |
| 0.5 | 10 | 25 | 0.5 | 0.6 | 2 | 0.73 |
| 0.6 | 10 | 25 | 1 | 0.6 | 2 | 1 |
| 0.8 | 10 | 25 | 1 | 0.6 | 2 | 1.25 |
| 1 | 10 | 25 | 1.1 | 0.6 | 2 | 1.77 |
| 1 | 15 | 40 | 1.5 | 2 | 4 | 1.85 |
| 1.2 | 10 | 25 | 1.1 | 2 | 4 | 2.21 |
| 1.2 | 15 | 40 | 1.5 | 2 | 4 | 2.3 |
| 1.5 | 15 | 40 | 1.5 | 1.8 | 4 | 2.77 |
| 1.5 | 23 | 60 | 2.6 | 2 | 3.6 | 2.77 |
| 2 | 18 | 50 | 2.1 | 2 | 4 | 3.69 |
| 2 | 22 | 60 | 2.6 | 2 | 4 | 3.69 |
| 3 | 40 | 80 | 3.8 | 2 | 4 | 5 |
| 4 | 50 | 100 | 4 | 2 | 2 | 11.15 |
| 4 | 60 | 120 | 4 | 2 | 7.5 | 4 |
| 4 | 80 | 180 | 4 | 2 | 10 | 3 |
| 4 | 100 | 200 | 4 | 2 | 12 | 2.5 |
| 4.5 | 50 | 100 | 5 | 2 | 2.7 | 11.15 |
| 5 | 50 | 100 | 5 | 1.4 | 2.6 | 12.39 |
| 5 | 75 | 150 | 5 | 2 | 10 | 3 |
| 6 | 50 | 100 | 6 | 2 | 2.5 | 17.35 |
| 8 | 50 | 100 | 8 | 2 | 2.1 | 28.26 |
Picture Show:
Factory & Certificate Show:
Company Website:
Skype: tianyuewangyeh
Send Inquiry to This Supplier
