204 Tractor (20HP 4WD Tractor)

204 Tractor (20HP 4WD Tractor) thumbnail-1
204 Tractor (20HP 4WD Tractor) photo-1
US$ 5,000 - 20,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Zhengzhou Dongfeng Mid-South Enterprise Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Other, Gear Drive, 4WD
Power(W) 14.7
Certificate EEC
Brand Name Dongfeng
Model Number 204
Place of Origin China
After-sales Service Provided Overseas service center available

Specifications

1, 20~50HP tractor EPA 4 approved
2, 16~50HP tractor EEC approved offer COC report
3, All OECD approved

204 tractor, 20hp 4wd tractor
-3 cylinder diesel engine
-6+2 Gearshift
-Single or dual stage clutch



Model

JM-204 tractor

Drive Type

4WD

Overall Dimensions
L*W*H(mm):

3080x1280x1930

Wheel Track(mm)

Front

1000-1100

Rear

1040-1200

Wheel Base(mm)

1645

Ground Clearance (mm)

295

Rated Traction Force(N)

4800

Construction Mass(kg)

1120

Min.Turning Radius(m)

2.5

Theoretical Speed(Without creeper)( km/h)

Forward

1.68,3.31,5.52,7.75,15.30,25.50
0.31,0.62,1.03,1.45,2.85,4.76

Reverse

1.33,6.15,0.25,1.15

Engine
Specifications

Model

  380

Type

3-Cylinder Vertical,water cooled,4 stroke cycle

Rated Power(kw/hp)

14.7/20

Rated Speed (rpm)

2400

Bore*Stroke(mm)

80*90

Total Displacement(L)

1.357

Drive
System

Clutch

Dual-Stage

Gear Box

(3+1)*2

Main Drive

One Pair of Spiral Bevel Gearing

Differential

Bevel Gear

Differential Lock

Jaw Lock

Final Transmission

External gearing, Spur Gear

Traveling
Mechanism

Tyre

Front

6.00-12

Rear

8.3-24

Steering Gear

Full Hydraulic Steering

Brake

Shoe type

Working
Device

Hydraulic System

Lifting Capacity at 610mm Behind Lift Point (N)

3600

3-Point Suspension

Category:I

P.T.O
Shaft

Speed (rpm)

540/1000

Spline Size

6-35Rectangular Spline
OPTIONS ROL BAR,CANOPY,SHUTTLE,HYDRAULIC STEERING,TURF TYRE,CAB
