4WD 304A Farm Tractor, Tractors From Dongfeng for Sale

4WD 304A Farm Tractor, Tractors From Dongfeng for Sale thumbnail-1
4WD 304A Farm Tractor, Tractors From Dongfeng for Sale photo-1
US$ 7,139 - 8,500 MOQ: 5 Sets
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Zhengzhou Dongfeng Mid-South Enterprise Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Gear Drive
Power(W) 22.1
Certificate EEC
Brand Name Dongfeng
Model Number DF304E
Place of Origin China
After-sales Service Provided Overseas service center available

Specifications

304D Farm tractor with 30hp:
1. High quality
2. Low price
3. Professional after-sale service

Specification:



1. ISO, EEC certificate

2. Nude packaging

3. 25-30 days after reception of the deposit



Tracor
Parameters

Model

DF-304A

Drive Type

4WD

Overall Dimensions L*W*H(mm):

3200x1280x1930

WheelTrack(mm)

Front

1100-1300

Rear

1040-1200

Wheel Base(mm)

1750

Ground Clearance (mm)

295

Rated Traction Force(N)

5980

Construction Mass(kg)

1400

Min.Turning Radius(m)

2.8

Theoretical Speed (With out creeper gear(km/h)

Forward

1.77,2.69,4.23,5.83,8.18,12.46,19.56,26.96

Reverse

2.33/11.25

Engine
Specifications

Model

ZN390T

Type

3-cylinder, Vertical
water-cooled,
4 stroke cycle

Rated Power(kw/hp)

22.1/30

Rated Speed (rpm)

2400

Bore*Stroke(mm)

90*95

Total Displacement(L)

1.813

Drive
System

Clutch

Dual stage

Gear Box

(4+1)*2

Main Drive

One Pair of Spiral Bevel Gearing

Differential

Bevel Gear

Differential Lock

Jaw Lock

Final Transmissions

Spur Gear,External,Gearing

Travelling
Mechanism

Tyre

Front

6.00-16

Rear

9.25-24

Steering Gear

Power Steering

Brake

Disc type

Working
Device

Hydraulic System

Lifting Capacity at 610mm Behind Lift Pioint (N)

5000

3-Point Suspension

Category:I

P.T.O Shaft

Speed (rpm)

540/720 or
540/1000

Spline Size

6- 35Rectangular Spline

OPTIONS

ROLL BAR,CANOPY,CAB
