244E Tractor, Farming Tractor, Tractors Price (20HP 4WD Tractor)

244E Tractor, Farming Tractor, Tractors Price (20HP 4WD Tractor) thumbnail-1
244E Tractor, Farming Tractor, Tractors Price (20HP 4WD Tractor) photo-1
US$ 5,000 - 20,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Wheel Tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Zhengzhou Dongfeng Mid-South Enterprise Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Wheel Tractor
By wheel 4WD
Usage Farm Tractor
Drive Type Other, Gear Drive, 4WD
Power(W) 24HP
Certificate EEC
Brand Name Dongfeng
Model Number 244E
Place of Origin China
After-sales Service Provided Overseas service center available

Specifications

1, 20~50HP tractor EPA 4 approved
2, 16~50HP tractor EEC approved offer COC report
3, All OECD approved

244E tractor, 20hp 4wd tractor
-3 cylinder diesel engine
-6+2 Gearshift
-Single or dual stage clutch











Tractor

Parameters

Model

JM-244E

Drive Type

4WD

Overall Dimensions

L*W*H(mm)

3185×1440×2530

Wheel  Track

(mm)

Front

1100

Rear

1040-1200

Wheel Bass(mm)

1645

Ground Clearance(mm)

295

Rated Traction Force(N)

5980

Construction Mass(kg)

1380

Min. Turning Radius(m)

2.80

Theoretical

Speed(km/h)

Forward

(creep)

1.73 3.42 5.71 8.01 15.80 26.40 0.32 0.64 1.06 1.49 2.95 4.92

Reverse

(creep)

1.37 6.35 0.26 1.18





Engine

Model

KM385TE

Type

3-Cylinder Vertical, Water Cooled, 4 Stroke Cycle

Rated Power(kw/hp)

17.6/24

Rated Speed(rpm)

2350

Bore×Stroke(mm)

85×90

Total Displacement(L)

1.532





Drive

System

Clutch

Dual-Stage

Gear Box

(3+1)×2

Main Drive

One Pair of Spiral Bevel Gearing

Differential

Bevel Gear

Different Lock

Jaw Lock

Final Transmission

Spur Gear, External Gearing



Traveling

Mechanism

Type

Front

6.00-16

Rear

9.5-24

Steering Gear

Full Hydraulic Steering

Brake

Shoe Type







Working Device





Hydraulic System

Lifting Capacity

at 610mm

Behind Lift Point(N)



4200

3-Point Suspension

Category:1

P.T.O

Shaft

Roating Speed(rpm)

540/1000

Spline Size

6-φ35Rectangular Spline

Options

Roll bar, Canopy, Shuttle, Hydraulic, Steering, Dual stage clutch,

Turf Tyer, Cab



Other Farming Tractor Series:

244E tractor, farming tractor, tractors price (20HP 4WD tractor)



Sales manager: Ms. Dream Chen

Dongfeng Group

Dongfeng Mid-south Enterprise Co., Ltd.

Cell: 0086-18538016313

Skype:overseas_dongfeng04
