Specifications
* unique surface grip* great flexibility
* Anti static
* Chemical resistance
* Temperature -70 to 260 degree Celsius
silicone impregnation fabric
As the largest supplier in China, FLEET manufacture silicone impregnation fabric with high quality woven glass and selected high temperature silicone rubber compounds.
Features:
1,temperature resistance, it can continuously work under -70℃ to 260℃.
2,weatherability: resistance to ozone, oxygen, sunlight and aging, long using life up to 10 years.
3,good electric insulator, dielectric constant 3~3.2, break down voltage between 20~50KV/mm.
Technical datasheet of silicone impregnation fabric:
Product. | thickness | Breaking strength (n/50mm) | Bursting strength Mpa | Combustibilty | Max width |
S015 | 0.15mm | 1500/1200 | 2.0 | ≤25% | 2450mm |
S025 | 0.25mm | 1800/1500 | 2.1 | ≤25% | 2450mm |
S040 | 0.40mm | 2000/1600 | 2.2 | ≤25% | 2450mm |
S060 | 0.60mm | 2400/2200 | 2.4 | ≤25% | 2450mm |
S080 | 0.80mm | 2600/2400 | 2.5 | ≤25% | 2450mm |
S100 | 1.00mm | 3000/2800 | 2.6 | ≤25% | 2450mm |
S150 | 1.50mm | 3700/3300 | 2.3 | ≤25% | 2450mm |
S200 | 2.00mm | 4200/3800 | 2.2 | ≤25% | 2450mm |
