Home > Transportation > Bus > Coach > Dongfeng 4x4 Off-road Desert Bus, Desert Bus, Off-highway Bus EQ5160XSGC With Cummins Engine
Dongfeng 4x4 Off-road Desert Bus, Desert Bus, Off-highway Bus EQ5160XSGC With Cummins Engine
US$ 50,000 - 150,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Seats:
16 - 30
Emission Standard:
Euro 3
Transmission Type:
Manual
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Dongfeng 4x4 EQ5160XSGC Off-road Desert Bus From China for SaleUS$ 135,000 - 140,000MOQ: 2 Sets -
Dongfeng Coast Bus EQ6700L4D Tourist Bus, Coach Bus, City BusUS$ 10,000 - 100,000MOQ: 1 Piece
-
Dongfeng Coast Bus EQ6790PT Tourist Bus, Coach Bus, City BusUS$ 10,000 - 100,000MOQ: 1 Piece
-
DONGFENG 4X4 EQ5160XSGC DESERT OFFROAD BusUS$ 35,000 - 133,000MOQ: 1 Unit
-
DONGFENG Desert 4x4 Off-road BusUS$ 35,000 - 133,000MOQ: 1 Unit
Seats
16 - 30
Emission Standard
Euro 3
Transmission Type
Manual
Condition
New
Engine Capacity
6 - 8L
Fuel Type
Diesel
Place of Origin
China
Brand Name
Dongfeng
Model Number
EQ5160XSGC
Specifications
1)Dongfeng EQ5160XSGC desert off-road bus2)CCC ISO9001:2000
3)Driving type 4*4
4)19-25 Seats
5)Diesel Euro II&III
The Specification:
| Product name and model | EQ5160XSGC | Drive mode | 4×4 |
| Size parameters | Overall dimensions: length×width×height(mm) | 7680×2500 (truck bed )2700(tire)×3380 | |
| Container inside dimension: length×width×height(mm) | 2835/1500×2375×1650 | ||
| Wheel base(mm) | 4500 | ||
| Tread(Front/Rear)(mm) | 2110(Cross-country tire)/2150(Desert tire) | ||
| Front overhang /Rear overhang (mm) | 1730/1450 | ||
| Approach angle /Departure angle (º) | 30/38 | ||
| Minimum ground clearance(mm) | 430 | ||
| Oil tank capacity (L) | 350 | ||
| Performance parameters | Maximum speed (km/h) | 76 | |
| Minimum turning diameter(m) | 19 | ||
| Maximum gradability (%) | 40 | ||
| Mass parameter | Unladen mass (kg) | 10200 | |
| Rated load mass (kg) | 4890 | ||
| Gross mass(kg) | 16000 | ||
| Engine | Model and variety | Straight inter-cooled 6-cylinder water-cooled diesel engine | |
| Model | ISDe245 30 | ||
| Discharge capacity(ml) | 6700 | ||
| Fuel type | Diesel | ||
| Rated power /speed (kW/r/min) | 180/2500 | ||
| Maximum torque /speed (N.m/r/min) | 900/1200-1700 | ||
| Cylinder diameter×travel route(mm×mm) | 114×135 | ||
| Compression ratio | 17.3:1 | ||
| Clutch | Model and type | Dry single disc clutch | |
| Control mode | Hydraulic remote control | ||
| Wearing piece diameter (mm) | φ430 | ||
| Transmission | Model, type | QJ1206)mechanical 6-gear | |
| Control mode | Soft shaft control | ||
| Forwardgear digit | 6 | ||
| Speed ratio | 9.013 5.241 3.223 2.201 1.504 1.0 R 8.3 | ||
| Auxiliary box | Speed ratio | 1.00 1.75 | |
| Frame | Structure type | Riveted structure | |
| Longitudinal beam cross dimensions (mm) | 280x80x8+4 | ||
| Electrical appliances | Electrical appliance line voltage(V) | 24 | |
| Accumulator modelquantity | 16-QA-180D 2 pieces | ||
| Generator Voltage/Current | 28V,70A | ||
| Number of passengers in the cab (number) | 13+1/19+1 | ||
| Chassis | Modeland type | EQ2161QGX60DJ | |
| Number of axles and tire | Number of axles | 2 | |
| Wheel felloe model | (Desert tire)14.00-20 ( Cross-country tire)10:00W-20 | ||
| Tire specification and tire number | (Desert tire)20-20 (Cross-country tire)14.00R20 4+1 | ||
| Redirector | Steering type | Power steering | |
| Frontgear | Type | Cast rigid axle housing with hub reduction gear | |
| Rated load(t) | Grade 7T | ||
| Reargear | Type | Cast rigid axle housing with hub reduction gear | |
| Rated load(t) | Grade 10T | ||
| Braking system | Auto brake type | 2-circuit air braking | |
| Auto brake boost type | Pneumatic servo boost | ||
| Brake power adjustment type | Manual | ||
| Brake type | Drum type | ||
| Parking brake type | Spring brake | ||
| Emergency brake type | Spring brake | ||
| Overhang frame | Front | Type | Road spring |
| Number of road springs | 11 | ||
| Rear | Type | Road spring | |
| Number of road springs | 14 | ||
Warranty Period: 12 months(calculating from the date the vehicle arrives at the destination port) or 50,000 kilometers, whichever comes first.
