Home > Electrical & Electronics > Sensor > Pressure Sensor > ETCR007AD /AC Leakage Current Clamp Sensor

ETCR007AD /AC Leakage Current Clamp Sensor

Name: ETCR007AD /AC Leakage Current Clamp Sensor
Brand: ETCR
SKU: 100476391
Availability: InStock

ETCR007AD /AC Leakage Current Clamp Sensor thumbnail-1

ETCR007AD /AC Leakage Current Clamp Sensor photo-1

US$ 130.21 - 130.21 MOQ: 1 Set

Key Specifications

Get Latest Price

Brand Name:

ETCR

Model Number:

ETCR007AD

Contact Supplier Request Quote Chat Now

Qingdao Zhibohongyu Trading Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name ETCR

Model Number ETCR007AD

Product Description

Introduction

ETCR 007AD AC/DC Clamp Leakage Current Sensor is designed for measuring AC/DC current and leakage current under 600V line voltage, by adopting the latest CT technology and digital integrate technology. The small clamp is suitable for line densely places (electric power measurement system, the high speed rail system, car circuit overhaul, and so on), non-contact measurement, to ensure safe operation. It is small, with high precision, stable performance, can be connected with phase detection analyzer, industrial control equipment, data recorder, oscilloscope, electric power quality analyzer, high precision multi-meter. The sensor is widely applied in those fields as electricity, communications, meteorology, railroad, car industry, oilfield, construction, measurement, scientific & research teaching institutes, industrial and mining establishments.

Technical Specifications

Function	Measurement of AC/DC current, leakage current
Power Supply	Zn-Mn dry battery, 6RL61, 9V. Continually using for 100 hours, connecting external power supply is also available for long time using.
Test Mode	Clip-on CT, non-contact measurement
Clamp Size	Φ7mm
Input Range	0mA-60.0A AC/DC
Output Voltage	10mV/A;100mV/A(corresponding)
Output Range	1V peak max
Resolution	1mA AC/DC
Accuracy	±3%FS(23C±5C, below 5%rh)
Phase Error	≤3°(AC 50Hz/60Hz; 23C±2C)
Calibration	Adjust ZERO to calibrate, eliminate external electric field interference
Output Wire	Core wire: signal positive output; shielding wire: signal ground
Lead length	2m
Dimension	LWH: 168mm×65mm×34mm
Frequency	AC: 45Hz-400Hz
Frequency	DC: DC-100kHz
Test Position	Tested wire in the jaw center
Line Voltage	AC600V
Weight	170g (Including the battery)
Working Current	5mA
Working Temperature and Humidity	-10C-50C,below 80%rh
Limit Temperature Error	-10C-0C and 40C-50C, within 2%rdg
Storage Temperature and Humidity	-10C-60C,below 70%rh
Insulating Strength	AC3700V/rms (between the alloy of the clamp and the housing)
Applicable safety rules	IEC1010-1, IEC1010-2-032, Pollution level 2, CAT III(600V)
Accessories	Sensor: 1piece; Battery(6F22,9V): 1piece; User Manual/Warranty card/ Certification: 1 copy
