Wall Mount charger 12V 1A
waht is specifications of our adapter
Features:
- Input:AC 110-240V 50/60HZ
- Output:DC 12V
- US,EU, AU,UK plug
- DC tips: you customize
- Output DC wire:1.2M
- Ripple noise:200mv
- Line regulation:+-5%
- load regulation:+-5%
Technical specification :
|
Input voltage Rated Voltage: 100~240Vac |
|
Variation Range: 80V~280Vac Input Frequency Rated Frequency: 50/60HZ Variation Frequency: 47~63Hz |
|
Input current 0.5Amax. at any input voltage and rated, DC output rated load. |
|
Inrush Current 30Amax. @ 264Vac input Efficiency: 80% min at 100Vac input and output rated .Load. |
|
Turn on delay time: 80% min at 100Vac input and output rated .Load. 3S max. @ 100 Vac to 240 Vac input & Full load Rise time 20mS max. @ Rated load Hold up time: 5mS min. @ Full load &230Vac/50Hz input turn off at worst case |
|
Short circuit protection: The power supply will be auto recovered when short circuit faults remove. Over current Protection: The power supply will be auto recovered when over current faults remove Over Voltage Protection: The power supply will auto recovered when faults remove 120%~150%. |
|
Environmental requirement: Operating Temperature: 0~40°C ,full load , normal operation. Storage Temperature: -20~80°C with package Relative Humidity: 10%(0°C) ~90%(40°C) RH |
Application :
Semiconductor refrigerator.Mini refrigeration equipment.Small home appliances.Tablet pc .Mobile phone . Game player . Musical instruments. Any Protable Device or Machine.
Tablet PC android 3 0, grinder, digital photo frame, Portable HDD Enclosure, HDD Player, portable DVD, Small and medium sized LED players, Other security products, etc.
Photos:
waht advantages of out adapters
Warranty:
1. We provide 1 year warranty.
2. Normal Production according to the sample that confirmed by customers or customer's instruction. So please do give us right and confirmed instruction as well as check the sample carefully before you confirm.
delivery time :
1. delivery time: 7-15 working days . it depends on the quantity you order ,we will try our best to satisfy your requirement.
2. Payment: TT or western Union
Reliability
- 1)Heat-resistance: The wall charger 12v 1A shall be stored at a temperature of 55+/-2 °C for 16 hours. Then No distortion and (Storage) it shall be subjected to standard astrospheres conditions for 2 hours,
- 2)Heat resistance: The wall charger 12v 1A shall be placed at a temperature of 25+/-2 °C and operating at No abnormity (Operation) full load for 4 hours. Measurement shall be made.
- (3)Cold-resistance: The wall charger 12v 1A shall be stored at a temperature of -20+/-2 °C for 16 hours. No distortion and (Storage) Then it shall be subjected to standard astrospheres conditions for 2 hour, No function error after which measurement shall be made.
- 4)Cold-resistance: The wall charger 12v 1A shall be placed at temperature of 0+/-2 °C and operating at No abnormity (Operation) rate75% full load for 4 hours. Measurement shall be made.
- 5)Body surface temp: at a environment temperature of 23+/-2 °C , 100VAC/2.0A load ≤65°CFor 2 hours, measure central section of sueface (thermoelectric couple method)
- 6) M.T.B.F: 50K Hours At 25°C With 80%Loading No abnormity
- 7) Life : Average Life Expectancy Or 3 Years
Testing :
