Home > Products > New Products > Security camera with pinhole lens mini camera/ ATM camera
Security camera with pinhole lens mini camera/ ATM camera
- 30000 Piece / Pieces per Month
- shenzhen
- T/T Credit Card PayPal
- 7 inch TFT Monitor DIGITAL Wireless Farm Cctv Systems
- 7 inch TFT Monitor DIGITAL Wireless New Backup Camera Kit with 2.4GHz digital signal
- 7 inch TFT Monitor Digital Reversing Camera System with 2.4GHz digital signal
- 7 inch TFT Monitor Wireless Back Up Systems with 2.4GHz digital signal
- Car Camera Wireless Transmitter System For Bus
- 7inch digital 2.4g wireless surveillance camera system For Bus
Product Details
Place of Origin: | Guangdong, China | Brand Name: | SOONY or OEM | Model Number: | SY-2300CDNP4 |
Style: | Mini Camera | Sensor: | CCD | Technology: | Pinhole |
Special Features: | Other | Type: | Other, Video Camera |
Product Description
Specifications
Mini Camera1/3"Sony CCD, 420TV Lines
2.5/2.8/6mm lens are optional
Audio is optional
2 years warranty, CE/FCC/RoHS
Security camera with pinhole lens mini camera/ ATM camera
Main Features:
- 1/3"Sony Super HAD CCD, 420TVL
- 3.7mm super cone pinhole lens, 2.5/2.8/6mm lens are optional
- Minimum Illumination: 0.1Lux(color)0.05Lux(B/W)
- Adopt full metal shell structure design, hard, prcatical
Why Choose us?
1. Soony is a professional cctv camera manufacturer for more than 7 years.
2. warranty: 2 years free of repair if has malfunctional under normal usage.
3. Your reliable business partner with low price and high quality.
Specifications/ Technical Parameters:
Model No. | SY-2300CDNP4 |
Image Pick-up Device | 1/3" Sony CCD |
Horizontal Resolution | 420TV Lines |
OSD | Available |
Number of Pixels | NTSC:510(H)x492(V); PAL:500(H)x582(V) |
Scanning System | NTSC:525Lines, 60 Field/sec, |
PAL:625Lines, 50 Field/sec | |
Sync System | Internal Synchronization |
Gamma Characteristic | 0.45 |
Lens | 3.7mm super cone pinhole lens,2.5/2.8/6mm lens are optional |
S/N Ratio | more than 48dB(AGC Off) |
Electronic Shutter Time | On: NTSC: 1/60~1/100,000Sec, PAL: 1/50~1/100,000Sec; |
Off: NTSC: 1/60Sec, PAL: 1/50Sec | |
Video Output | 1.0Vp-p 75ohm |
Minimum illumination | 0.1Lux(color)0.05Lux(B/W) |
Audio | optional |
Gain Control(AGC) | Auto |
Operation Temperature | -10C~+50C RH95%MAX |
Storage Temperature | -20C~+60C RH95%MAX |
Power Supply | DC12V+_10%,120mA |
Dimension | 30X30mm |
Case | Black |
