Plastic Dome Camera Color CCD Camera/Low Lux(SY-6030D Series )

Plastic Dome Camera Color CCD Camera/Low Lux(SY-6030D Series ) thumbnail-1
Plastic Dome Camera Color CCD Camera/Low Lux(SY-6030D Series ) photo-1
US$ 16 - 47 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SOONY or OEM
Model Number:
SY-6030D series
Contact Supplier Request Quote Chat Now
Shenzhen Isec Technologies Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SOONY or OEM
Model Number SY-6030D series
Style Dome Camera
Sensor CCD
Technology Other
Type Other, Video Camera

Specifications

Plastic Dome Camera
Sony/Sharp CCD optional
420/480/540/600/700tvl optional
3.6mm board lens
CE/FCC/RoHS, 2Y Warranty

Plastic Dome Camera Sony CCD Camera/Low Lux(SY-6030D series )



  Main Features:

  • power supply DC12V,120mA
  • color reproduction is good,clear picture quality
  • 3.6mm board lens, 1.8/2.8/6mm boad lens are optional
  • gamma characteristic 0.45
  • scanning system NTSC/PAL

 Specifications:



Model

SY-6037D

SY-6036D

SY-6034D

SY-6030HD

SY-6030D

SY-6032D

SY-6033D

Image Sensor

1/3" SONY ICX673AK CCD

1/3" SONY ICX639BK CCD

1/3" SONY ICX639BK CCD

1/3" SONY ICX633BK CCD

1/3" SONY ICX633BK CCD

1/3" SHARP RJ2321FA CCD

1/4" SHARP RJ2421FA CCD

Horizontal Resolution

700TV Lines               Hi-sensitivity           Effio, ATR, OSD, NR

600TV Lines Hi-sensitivity, OSD

540TV Lines             Hi-sensitivity

480TV Lines            Hi-sensitivity

420TV Lines         Hi-sensitivity

420TV Lines         Hi-sensitivity

420TV Lines         Hi-sensitivity

TV System

PAL/NTSC

Effective Pixels

PAL:976 (H)?494(V) NTSC:976 (H) ?82 (V)

PAL:795 (H)?596(V),                                      NTSC:811 (H) ?08 (V)

PAL:752(H)x582(V) NTSC:768(H)x494(V)

PAL:500(H)x582(v)
NTSC:510(H)x492(v)

Lens

3.6mm board lens

1.8/2.1/2.8/6mm board lens are optional

Minimum Illumination

   0.001 Lux/F2.0

0.01 Lux/F2.0

0.5 lux/F2.0

Scanning System

    NTSC:525 Lines,60 Field/sec,

    PAL:625 Lines 50 Field/sec

Sync System

    Internal Synchronization

Gamma Characteristic

0.45

S/N Ratio

=65dB (AGC OFF)

=54dB (AGC OFF)

=48dB (AGC OFF)

Electronic Shutter Time

    NTSC 1/60~1/100,000Sec,PAL 1/50~1/100,000Sec;

Video Output

Composite Signal (1.0Vp-p, 75O), BNC

Gain Control(AGC)

adjustable

auto

White Balance

adjustable

auto

Backlight Compensation

adjustable

auto

Operation Temperature

    -10C~ +50C RH95% MAX

Storage Temperature

    -20C~ +60C RH95% MAX

Power Supply

    DC12V,120mA

Dimension

Ø100X70mm

weight

    0.3kg



Our warrranty:

We provide a 2-year warranty based on our ship date. We will repair or replace our merchandise which is defective with normal usage by the way of free of charge. We are confident that our products are of high quality when shipped to our customers.
