IR Camera Dome Shape/globe Shape

IR Camera Dome Shape/globe Shape thumbnail-1
IR Camera Dome Shape/globe Shape photo-1
US$ 26 - 49 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SOONY or OEM
Model Number:
SY-IR3057DMW
Contact Supplier Request Quote Chat Now
Shenzhen Isec Technologies Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name SOONY or OEM
Model Number SY-IR3057DMW
Type Other, Analog Camera, Video Camera
Style Dome Camera
Sensor CCD
Technology Infrared
Special Features Waterproof / Weatherproof

Specifications

IR camera
100% factory of cctv camera
30m IR range
Auto white balance & gain control
2Y warranty, CE/FCC/RoHS



IR camera dome shape/globe shape



Specifications:

  1. 700TVL use sony effio-e ccd
  2. 700/600TVL has OSD control cable
  3. 4-9mm manual zoom lens
  4. IP66 waterproof
  5. 2y warranty guarranteed, CE/FCC/RoHS







Model

SY-IR3057DMW

SY-IR3056DMW

SY-IR3054DMW

SY-IR3050HDMW

SY-IR3050DMW

SY-IR3052DMW

SY-IR3053DMW

Image Sensor

1/3" SONY ICX673AK CCD

1/3" SONY ICX639BK CCD

1/3" SONY ICX639BK CCD

1/3" SONY ICX633BK CCD

1/3" SONY ICX633BK CCD

1/3" SHARP RJ2321FA CCD

1/4" SHARP RJ2421FA CCD

Horizontal Resolution

700TV Lines      Hi-sensitivity         Effio, ATR, OSD NR

600TV Lines Hi-sensitivity, OSD

540TV Lines  Hi-sensitivity

   480TV Lines    Hi-sensitivity

420TV Lines Hi-sensitivity

420TV Lines Hi-sensitivity

420TV Lines  Hi-sensitivity

TV System

PAL/NTSC

Effective Pixels

PAL:976 (H)x494(V) NTSC:976 (H) 582 (V)

      PAL:795 (H)x596(V),       NTSC:811 (H) 508 (V)

PAL:752(H)x582(V) NTSC:768(H)x494(V)

       PAL:500(H)x582(v)                              NTSC:510(H)x492(v)

IR LED

   36pcs Ø5mm IR LEDs

IR project distance

    30 meters

Lens

  standard: 4-9mm manual zoom lens

2.8-12mm manual zoom lens is optional

Minimum Illumination

   0 Lux/F2.0 (LED ON)

IR Status

    Under 10 Lux by CDS

IR Power On

    CDS Auto Control

Scanning System

    NTSC:525 Lines,60 Field/sec,

    PAL:625 Lines 50 Field/sec

Sync System

    Internal Synchronization

Gamma Characteristic

0.45

S/N Ratio

=65dB (AGC OFF)

=54dB (AGC OFF)

=48dB (AGC OFF)

Electronic Shutter Time

    NTSC 1/60~1/100,000Sec,PAL 1/50~1/100,000Sec;

Video Output

Composite Signal (1.0Vp-p, 75O), BNC

Gain Control(AGC)

    Auto

White Balance

    Auto

Backlight Compensation

    Auto

Operation Temperature

    -10C~ +50C RH95% MAX

Storage Temperature

    -20C~ +60C RH95% MAX

Waterproof

    IP66

Power Supply

    DC12V,400mA

Dimension

Ø119X83(H)mm

Camera Case Color

   default: purple

white, black, silver, new grey are optional
