USB Contact Smart IC Chip Card Reader and Writer ACR38
- Ø Due to the rising demand of e-working methods (remote office, home office...) and the increasing risk of unauthorized access to private network, it is time to properly secure access to PCs, desktops, and the Intranet and Extranet networks. ACR38 offers solutions based on smart card readers (connected to PCs) for access control.
- Ø The ACR38smart card reader/writer is a USB full speeddevice whichthe interface is for communication between a computer and a smart card. It is designed for the PC environmentand is the ultimate smart card peripheral for a PC.
- Ø ACR38 is a key partner of the PC as smart card is becoming an essential component in network security and electronic payment system. Providing secured networkenvironment by its data encryption function, the SDK package allows users to develop their own application easily to meet their specific system needs.
- Ø ACR38 is a low cost, yet reliable and effective smart card toPC interface with design focusing on convenient use and harmony with other PC peripherals in shape and color. It provides the solution where the security of a smart card is required. It can be used as access control to a computer or network (intranet, extranet ...), authentication for e- commerce (B to B, B to C) ... It is very simple to use and install. It is ideal for electronic commerce, home banking or e-purse facilities, secure computer access or any of a multitude of other application
Features
USB full speed interface to PC with simple command structure
Read and write all microprocessor cards with T=0 or T=1 protocols
Support SLE 4418/28/32/42 memory cards
Support most common memory-based smart cards, including I2C bus protocol cards (from 1k bits up to 1024k bits) and secure memory cards (Atmel AT88SC153 and AT88SC1608)
Support 1.8V, 3V and 5V MCU cards
Short Circuit Protection
Certificate of conformance: ISO 7816-1/2/3, PC/SC, CE, FCC, Microsoft WHQL, EMV certified
ISO7816-1/2/3 compatible smart card interface ,
Support PPS (Protocol and Parameters Selection) with 1743 – 307200 bps in reading and writing smart cards
768 bytes RAM size and 16K bytes ROM size
Extra SAM slot is optional
Typical Applications
- Ø Home Banking and Home Shopping
- Ø E-Commerce
- Ø Checkthe balance of account of re-loading an e-purses
- Ø Network access control
- Ø S/W locking
- Ø Digital signature
- Ø Loyalty and promotions
- Ø Stored value
- Ø Identification
- Ø Ticketing
- Ø Parking and toll collection
- Ø Online gaming
More Details
Universal Serial Bus Interface | |
Type |
USB full speed, four lines: +5V, GND, D+ and D- |
Power source |
From USB |
Speed |
12 Mbps |
Smart Card Interface | |
Standard |
ISO 7816 1/2/3, T=0 and T=1 |
Supply current |
Max. 50mA |
Smart card read / write speed |
1743 – 307200 bps |
Short circuit protection |
+5V / GND on all pins |
The presence of the smart card power supply voltage is indicated through a green LED on the reader | |
CLK frequency |
4 MHz |
Card connector |
Contact mode |
Card insertion cycles |
min. 100,000 |
(Optional) SAM Card Interface | |
Card connector |
Landing |
Location |
Under the removable dark lid |
Physics | |
Dimensions |
97mm (L) x 72mm (B) x 18.5mm (H) |
Color |
White |
Environment | |
Temperature |
0 - 50° C |
Humidity |
40% - 80% |
Standard/Certificate |
EMV Level 1, ISO7816-1/2/3, PC/SC, CE, FCC, Microsoft WHQL ME, 2K, XP |
Operating System |
Windows 98, ME, 2K, XP |
OEM |
Possible OEM-Logo, customer-specific colors, casing, and card connector |
2.Product images
established in 2008 ,Our conpany has two main offices located in Hong Kong and Shenzhen, China. Our company is founded by a group of passionate and creative people with rich RFID trading and manufacture experience.
Our company is specialized in various RFID tags and labels with different shapes and materials. Our tags range from low frequency to ultra-high frequency, which are widely used in NFC field, mobile payment, access control, supply chain management, inventory management, storage & logistics management, livestock management and so on.
Our company not only involves the R&D of RFID tags, manufacturing, sales but also provides technical consulting service and support. Customized service is available for our customers to customize their tags and labels in terms of function, shape and material.
Choose Toptag, Choose Quality and Service
1. High Quality Control ----We have strict QC system, Twice QC lines arranged before delivery.
2. High Reputation ---- Our clients include many World Brand Companies.
3. Responsible Sales ----We concern what you concern.
4. All-around ON TIME service ---- We work late to meet your urgent needs.
5. Competitive Price----OEM supplier offering direct Factory price.
6. On Time Deliver ---- Powerful production capability ensure shortest deliver schedule.
We have been trying our best to prove ourselves to be your Best Reliable Professional supplier .
FAQ
Q1: I’m interested in your products, but now I’m out of China; could you offer you labels to my country?
A1: Sure! We’ve got full exportation experience, and no matter where you are, we may arrange the delivery.
Q2: Could I get the free samples for testing?
A2: Yes, we could provide free samples for your testing.
Q3: Is it possible to custom the labels with my own design?
A3: Yes, and you just need send us your drawings or artworks, then you can get what you want.
Q4:Do you provide OEM service?
A4: Yes. Actually, we’re already OEM for some brand, and also do the specific packing for them.
Q5: Can I get Sales support?
A5: Definitely. Our products have been strictly tested by QC before delivery.
Taking photos of products before delivery.
Q6: How many days can I get my products?
A6: Normally within one week. If you have urgent request, please just let us know. We will try our best to shorten the lead time to meet your requirements.
Following is the normal shipping time for your reference.
DHL: 3-5days
UPS: 4-5days
FedEx: 6-7days
TNT: 6-7days
By sea: 25-35days
Q7: How can I release the payment to you?
A7: We can receive your payment by L/C,T/TPaypal, Western union or Bank Account.
If you have any questions, please feel free to contact us
