Factory price CCTV manufacturer CCTV mirror camera with Sony ccd on sale

Specifications

CCTV manufacturer camera
2Y warranty
Fast delivery & T/T for payment
8Y factory experience
CE/FCC/ROHS



 Factory price CCTV manufacturer CCTV mirror camera with Sony ccd on sale$



Features



1. Smoke Detector Hidden Camera

2. Sony Color CCD or Sharp Color CCD option

3. Sony Low Illumination CCD 0.1lux

4. Sharp ccd 0.5lux

5. High definition up to 700TVL(650/540/480/ 420TVL option)

6. 700TVL and 650TVL camera with built-in OSD, controlled by OSD cable

7. Standard lens:   3.6mm board lens  2.1/2.8/6 mm pinhole lens are optional
8. Without IR LED

9.  5", 12",  16" mirror  are optional

10. Ø92x80(H)mm
11.  0.4kg

Model	IC-H-FSR	IC-H-FSS	IC-H-FSQ	IC-H-FHM	IC-H-FSK	IC-H-FSF
Image Sensor	1/3" SONY 960H CCD	1/3" SONY 960H CCD	1/3" SONY 760H CCD	1/3" SHARP 760H CCD	1/3" SONY Super HAD II CCD	1/3" SONY Super HAD II CCD
CCD model no.	ICX811AK(PAL) ICX810AK(NTSC)	ICX811AK(PAL) ICX810AK(NTSC)	ICX639BK(PAL) ICX638BK(NTSC)	RJ2365DB(PAL) RJ2355DB(NTSC)	ICX633BK(PAL) ICX632BK(NTSC)	ICX633BK(PAL) ICX632BK(NTSC)
DSP model no.	AVS03P	Effio-E CSD4140GG	Nextchip 2040E	Nextchip 2040E	Nextchip 2030E	SONY CXD3142R
Horizontal Resolution	800TVL OSD	700TV Lines OSD	650TV Lines OSD	650TV Lines OSD	480TV Lines Hi-sensitivity	420TV Lines Hi-sensitivity
TV System	PAL / NTSC
Effective Pixels	PAL:1020(H)*596(V) NTSC:1020H*508(V)		PAL:752(H)*582(V) NTSC:768(H)*494(V)		PAL:500(H)*582(V) N:510(H)*492(V)
Lens	3.6mm board lens, 1.8/2.1/2.5/2.8/6/8/12/25mm pinhole lens are optional
Scanning System	2:1 Interlace
Sync System	Internal Synchronization
S/N Ratio	More than 48dB(AGC OFF)
Electronic Shutter Time	NTSC 1/60~1/100,000Sec; PAL 1/50~1/100,000Sec
Video Output	1Vp-p,75ohm, BNC
Gain Control(AGC)	adjustable				Auto
White Balance	adjustable				Auto
Backlight Compensation	adjustable				Auto
Mirror	ON/OFF
Privacy Masking	ON/OFF (8 areas)
Operation Temperature	-10C~ +50C RH95% MAX
Storage Temperature	-20C~ +60C RH95% MAX
Power Supply	DC12V, 300mA
Dimension	Ø92x80(H)mm
Case Color	Black
Weigt	0.4kg

Deatails



Name of products

Mirror Housing Smallest Hidden Camera



Model number

IC-H-F series

Why choose us?

u  Provide one-stop-products: from CCTV camera, IP camera to DVR, video balun, etc to meet your whole project needs.

u  9 years R&D and export experience and leading and professional manufacturer in CCTV industry.

u  High quality (material) with competitive and reasonable price.

u  2 year warranty and lifetime maintenance.

u  Fast delivery: usually within 3-10 work days since payment arrived.

u  Professional technical support; Best pre-sale, sale and after-sale service.

u  Welcome OEM & ODM, mixed order.

u  CE, FCC, RoHS passed.

Quality Control:

u  All raw materials are carefully selected and inspected.

u  Advanced production equipment is used and routinely inspected and serviced.

u  All operators and employees are thoroughly trained.

u  All products have passed the European Union RoHS standard and are CE, FCC certified.

u  Professional logistics personnel are employed to control the damage during the physical distribution of products.





Questions about our CCTV manufacturer camera:

u  Q: How long is the warranty?

u  A: 2 -years-warranty since delivered out.

u  Q: What's the MOQ?

u  A: 1pc for sample, 20pcs for OEM order.

u  Q: How long is the delivery time?

u  A: Sample order 3-5 working days, bulk order 5-10 working days.

u  Q: How do make payment?
