650TVL Outdoor Cctv Hd Sdi Camera

Name: 650TVL Outdoor Cctv Hd Sdi Camera
Brand: ISEC
SKU: 100466951
Availability: InStock

Negotiable MOQ: 2 Units (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ISEC

Model Number:

IC-LBW20-F Series

Shenzhen Isec Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ISEC

Model Number IC-LBW20-F Series

Type Other, Digital Camera, Video Camera

Style Bullet Camera

Sensor CCD

Technology Infrared

Special Features Waterproof / Weatherproof

Specifications

1.650TVL Outdoor Cctv Hd Sdi Camera
2.2.8/6mm lens are optional
3.CE, FCC ROHS
4.2 year warranty
5.OEM

650TVL Outdoor Cctv Hd Sdi Camera

Features:

1. 700TVL Day&Night Outdoor Waterproof IR CCTV Hd Sdi Camera

2. Waterproof IR CCTV Camera

3. IR LEDS: 24pcs Ø5mm

4. 700TVL and 600TVL camera with built-in OSD

5. IR Lens: 3.6mm board lens 2.8-6mm lens is optional

Specifications

Model	IC-LBW20-FSS	IC-LBW20-FSQ	IC-LBW20-FSM	IC-LBW20-FSK	IC-LBW20-FSF	IC-LBW20-FHA
Image Sensor	1/3" SONY ICX673AK CCD	1/3" SONY ICX639BK CCD	1/3" SONY ICX639BK CCD	1/3" SONY ICX633BK CCD	1/3" SONY ICX633BK CCD	1/4" SHARP RJ2421FA CCD
Horizontal Resolution	700TV Lines Hi-sensitivity Effio, ATR, OSD, NR	600TV Lines Hi-sensitivity, OSD	540TV Lines Hi-sensitivity	480TV Lines Hi-sensitivity	420TV Lines Hi-sensitivity	420TV Lines Hi-sensitivity
TV System	PAL/NTSC
Effective Pixels	PAL:976 (H)× 494(V) NTSC:976 (H) ×582 (V)	PAL:795 (H)× 596(V), NTSC:811 (H) ×508 (V)		PAL:752(H)x582(V) NTSC:768(H)x494(V)	PAL:500(H)x582(v) NTSC:510(H)x492(v)
IR LED	24pcs Ø5mm IR LEDs
IR project distance	20 meters
Lens	standard: 3.6mm board lens
	2.8/6mm lens are optional
Minimum Illumination	0lux with IR on
IR Status	Under 10 Lux by CDS
IR Power On	CDS Auto Control
Scanning System	NTSC:525 Lines,60 Field/sec,
	PAL:625 Lines 50 Field/sec
Sync System	Internal Synchronization
Gamma Characterlstic	0.45
S/N Ratio	≥65dB (AGC OFF)	≥54dB (AGC OFF)		≥48dB (AGC OFF)
Electronic Shutter Time	NTSC 1/60~1/100,000Sec,PAL 1/50~1/100,000Sec;
Video Output	Composite Signal (1.0Vp-p, 75Ω), BNC
Gain Control(AGC)	Auto
White Balance	Auto
Backlight Compensation	Auto
Operation Temperature	-10C~ +50C RH95% MAX
Storage Temperature	-20C~ +60C RH95% MAX
Waterproof	IP66
Power Supply	DC12V,400mA
Dimension	Ø100(W) x65(H) x71(D)mm
Camera Case Color	default:blue and grey
weigt	0.45kg
