Specifications
9v 2a car charger for Ingenico ALI01561. input: 110v -240v
2.output: 9v 2a
tection:OVP,SCP,OCP
9v 2a car charger for Ingenico ALI0156
1.Features:
1.input:12v-24v
2.output:DC9v 2a
tection: OCP,OVP,SCP
4.warraty:1 year
5. High Performance Car Charger
2.Technical specification :
|
Input voltage Rated Voltage: 100~240Vac |
|
Variation Range: 80V~280Vac Input Frequency Rated Frequency: 50/60HZ Variation Frequency: 47~63Hz |
|
Input current 0.5Amax. at any input voltage and rated, DC output rated load. |
Inrush Current 30Amax. @ 264Vac input Efficiency: 80% min at 100Vac input and output rated .Load. |
|
Turn on delay time: 80% min at 100Vac input and output rated .Load. 3S max. @ 100 Vac to 240 Vac input & Full load Rise time 20mS max. @ Rated load Hold up time: 5mS min. @ Full load &230Vac/50Hz input turn off at worst case |
|
Short circuit protection: The power supply will be auto recovered when short circuit faults remove. Over current Protection: The power supply will be auto recovered when over current faults remove Over Voltage Protection: The power supply will auto recovered when faults remove 120%~150%. |
Environmental requirement: Operating Temperature: 0~40°C ,full load , normal operation. Storage Temperature: -20~80°C with package Relative Humidity: 10%(0°C) ~90%(40°C) RH |
3.Charger :
Ingenico ALI0156 /Ingenico i7910
4.Warranty:
1. We provide 1 year warranty.
2. Normal Production according to the sample that confirmed by customers or customer's instruction. So please do give us right and confirmed instruction as well as check the sample carefully before you confirm
3. Should you need any assistance with product problems or for warranty claims please feel free to contact us. You will receive a prompt reply from us
5.Photos :
6.Reliability:
- 1)Heat-resistance: The 9v 2a car charger for Ingenico ALI0156shall be stored at a temperature of 55+/-2 °C for 16 hours. Then No distortion and (Storage) it shall be subjected to standard astrospheres conditions for 2 hours,
- 2)Heat resistance: The 9v 2a car charger for Ingenico ALI0156shall be placed at a temperature of 25+/-2 °C and operating at No abnormity (Operation) full load for 4 hours. Measurement shall be made.
- (3)Cold-resistance: The 9v 2a car charger for Ingenico ALI0156shall be stored at a temperature of -20+/-2 °C for 16 hours. No distortion and (Storage) Then it shall be subjected to standard astrospheres conditions for 2 hour, No function error after which measurement shall be made.
- 4)Cold-resistance: The 9v 2a car charger for Ingenico ALI0156shall be placed at temperature of 0+/-2 °C and operating at No abnormity (Operation) rate75% full load for 4 hours. Measurement shall be made.
- 5)Body surface temp: at a environment temperature of 23+/-2 °C , 100VAC/2.0A load ≤65°CFor 2 hours, measure central section of sueface (thermoelectric couple method)
- 6) M.T.B.F: 50K Hours At 25°C With 80%Loading No abnormity
- 7) Life : Average Life Expectancy Or 3 Years
