High compression H.264 real-time 4CH dvr recoder

Specifications

High compression H.264 real-time 4CH dvr recoder
Support IE / phone
Support client software
VGA output
Support PTZ / NAT

High compression H.264 real-time 4CH dvr recoder







Main Fetures



♦  H.264 real-time high compression, support dual stream network transmission
♦  Video output:VGA and BNC can be independent local output.VGA display resolution max to 1280*1024
♦  Realtime display resolution: D1(4CIF) 704*576 (PAL),D1(4CIF) 704*480(NTSC)
♦  Backup: CD-RW (Option: DVD-RW), USB 2.0 and NET backup supported
♦  Search& playback Categories:channel, Date/Time, Event
♦  RJ-45 Ethernet connector,support Static, Dynamic IP and support TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SMTP
♦  Support NAT: network adress transfer, no need router and port setting unless network connecting
♦  Support IE,Mobile phone and special client software
♦  Support Pelco-P&Pelco-D PTZ control
♦  Support the partial graphic of monitoring to be enlarged onmousedrag
♦  Multi-language OSD



Specification



Compression standard	H.264
Video input	BNC(1.0V p-p/75Ω)×4-channel
Video output	BNC(1.0V p-p/75Ω)×1-channel
	VGA×1,800×600,1024×768,1280×1024
Audio input	RCA(2.0Vp-p/600Ω)×1-channel
Audio output	RCA(600Ω)×1-channel
Display resolution	D1
Playback resolution	4D1
Frame rate	0.1F/S-25F/S(PAL)   0.1 F/S-30 F/S(NTSC)
Stream set	Adjustable five-speed stream
HDD	1SATA
Network interface	10/100M
USB interface	USB2.0*2
RS485 interface	1
Power supply	DC12V/2A
Power(without HDD)	≤8W
Work temperature	-10°C- +55°C
Humidity	10%-90%



Boxing



DVR size:255*215*45mm

N.W.: 0.90kg

G.W.:1.26kg
Color box size:355*275*100mm

5pic/ctn: 525*385*305mm
PKG G.W.: 7.16kg



Inluding

DVR:1                 Manual:1                   Certificate:1

Disk:1                 Mouse:1                    Screw:1

Power line:1      Power Adapter:1      SATA dataline:1
