700tvl Effio-e Sony Ccd Low Price of Hidden Cameras (IC-H-A)

700tvl Effio-e Sony Ccd Low Price of Hidden Cameras (IC-H-A) thumbnail-1
700tvl Effio-e Sony Ccd Low Price of Hidden Cameras (IC-H-A) photo-1
US$ 19.4 - 37.7 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ISEC
Model Number:
IC-H-A
Contact Supplier Request Quote Chat Now
Shenzhen Isec Technologies Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name ISEC
Model Number IC-H-A
Type Analog Camera
Style Hidden Camera
Sensor CCD
Technology Pinhole
Special Features Other

Specifications

-Fast delivery!
-Hidden cameras!
-2 Years Warranty (fcc/ce/rohs)!
-100% cctv manufacturer!
-1 unit mini order!



700tvl effio-e sony ccd low price of hidden cameras (IC-H-A)





Features





1. Metal UFO Hidden camera

2. Sony Color CCD or Sharp Color CCD option

3. Sony Low Illumination CCD 0.1lux

4. Sharp ccd 0.5lux

5. High definition up to 700TVL(650/540/480/ 420TVL option)

6. 700TVL and 650TVL camera with built-in OSD, controlled by OSD cable

7. Standard lens: built-in 3.7mm pinhole lens 2.8mm pinhole lens is optional

8. Without IR LED

9. Ø86x60mm

10. 0.35kg



Deatails



Name of products

700tvl effio-e sony ccd low price of hidden cameras (IC-H-A)



 Model number

IC-H-A series







Model IC-H-ASS IC-H-ASQ IC-H-ASM IC-H-ASK IC-H-ASF
Image Sensor 1/3" SONY ICX673AK CCD 1/3" SONY ICX639BK CCD 1/3" SONY ICX639BK CCD 1/3" SONY ICX633BK CCD 1/3" SONY ICX633BK CCD
Horizontal Resolution 700TV Lines               Hi-sensitivity           Effio, ATR, OSD, NR 600TV Lines Hi-sensitivity, OSD 540TV Lines             Hi-sensitivity 480TV Lines           Hi-sensitivity 420TV Lines         Hi-sensitivity
TV System PAL/NTSC
Effective Pixels PAL:976 (H)× 494(V) NTSC:976 (H) ×582 (V) PAL:795 (H)× 596(V),                                     NTSC:811 (H) ×508 (V) PAL:752(H)x582(V) NTSC:768(H)x494(V) PAL:500(H)x582(v)
NTSC:510(H)x492(v)
IR LED    without IR LED
Lens built-in 3.7mm pinhole lens
2.8mm pinhole lens is optional
Minimum Illumination 0.1(day)/0.01(night)Lux 0.1Lux
Scanning System    NTSC:525 Lines,60 Field/sec,
   PAL:625 Lines 50 Field/sec
Sync System    Internal Synchronization
Gamma Characterlstic 0.45
S/N Ratio ≥65dB (AGC OFF) ≥54dB (AGC OFF) ≥48dB (AGC OFF)
Electronic Shutter Time    NTSC 1/60~1/100,000Sec,PAL 1/50~1/100,000Sec;
Video Output Composite Signal (1.0Vp-p, 75Ω), BNC
Gain Control(AGC)    Auto
White Balance    Auto
Backlight Compensation    Auto
Operation Temperature    -10C~ +50C RH95% MAX
Storage Temperature    -20C~ +60C RH95% MAX
Waterproof    IP66
Power Supply    DC12V,400mA
Dimension Ø86x60mm
Camera Case Color Grey
weigt    0.35kg







700tvl effio-e sony ccd low price of hidden cameras (IC-H-A)







Other hidden cameras







 700tvl effio-e sony ccd low price of hidden cameras (IC-H-A) 700tvl effio-e sony ccd low price of hidden cameras (IC-H-A) 700tvl effio-e sony ccd low price of hidden cameras (IC-H-A)700tvl effio-e sony ccd low price of hidden cameras (IC-H-A)700tvl effio-e sony ccd low price of hidden cameras (IC-H-A)
