1/3" Sony Metal UFO Hidden Ccd Camera

Name: 1/3" Sony Metal UFO Hidden Ccd Camera
Brand: ISEC OR OEM
SKU: 100464507
Availability: InStock

US$ 17.4 - 44.8 MOQ: 20 Units

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ISEC OR OEM

Model Number:

IC-H-B

Shenzhen Isec Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ISEC OR OEM

Model Number IC-H-B

Type Analog Camera

Style Hidden Camera

Sensor CCD

Technology Pinhole

Special Features Other, UFO hidden ccd camera

Specifications

1/3" Sony metal UFO Hidden ccd camera
built-in 3.6mm board lens
1/3" Sony Effio-E 960H CCD
super WDR, 3DNR , OSD

Product Description

Features:

SONY/SHARP 960H Color CCD, SONY Super HAD II CCD, SHARP hi-sensitivity CCD option

800TVL, 700TVL, 650TVL, 480TVL, 420TVL option

3.6mm board lens , 2.1/2.8/6 mm pinhole lens are optional

Silver Case

DC12V, 100MA

Specifications:

Model NO.	IC-H-BSR	IC-H-BHO	IC-H-BSO	IC-H-BSS	IC-H-BSF	IC-H-BHA
VIDEO
Image Device	1/3" SONY 960H CCD	1/3" SHARP 960H CCD	1/3" SONY 960H CCD	1/3" SONY 960H CCD	1/3" SONY Super HAD II CCD	1/4" SHARP CCD
CCD model no.	ICX811AK(PAL) ICX810AK(NTSC)	RJ2341(PAL) RJ2331(NTSC)	ICX811AK(PAL) ICX810AK(NTSC)	ICX811AK(PAL) ICX810AK(NTSC)	ICX633BK(PAL) ICX632BK(NTSC)	RJ2421FA(PAL) RJ2411FA(NTSC)
DSP model no.	AVS03P	Nextchip 2090E	Nextchip 2090E	Effio-E CSD4140GG	SONY CXD3142R	SHARP LR38627
Horizontal Resolution	800TVL			700TVL	420TVL
TV System	PAL/NTSC
Total Pixels	PAL:1020(H)596(V) , NTSC:1020H508(V)				PAL:537(H)597(V) NTSC:537(H)505(V)
Effective Pixels	PAL:960(H)582(V) , NTSC:976H494(V)				PAL:500(H)582(V) NTSC:510(H)492(V)
Scanning System	2:1 Interlace
Synchronization	Internal
Min. Illumination	0.01Lux	0.1Lux		0.01Lux		0.1Lux
S/N Ratio	More than 48dB(AGC OFF)
Video Output	1Vp-p,75ohm, BNC
