Home > Security & Protection > Surveillance, Control & Protection > CCTV Camera > 1/3 Cmos Sensor 20m IR Outdoor 960P 1.3MP AHD Camera

1/3 Cmos Sensor 20m IR Outdoor 960P 1.3MP AHD Camera

Name: 1/3 Cmos Sensor 20m IR Outdoor 960P 1.3MP AHD Camera
Brand: ISEC or OEM
SKU: 100463663
Availability: InStock

1/3 Cmos Sensor 20m IR Outdoor 960P 1.3MP AHD Camera thumbnail-1

1/3 Cmos Sensor 20m IR Outdoor 960P 1.3MP AHD Camera thumbnail-2

1/3 Cmos Sensor 20m IR Outdoor 960P 1.3MP AHD Camera thumbnail-3

1/3 Cmos Sensor 20m IR Outdoor 960P 1.3MP AHD Camera thumbnail-4

1/3 Cmos Sensor 20m IR Outdoor 960P 1.3MP AHD Camera thumbnail-5

1/3 Cmos Sensor 20m IR Outdoor 960P 1.3MP AHD Camera thumbnail-6

1/3 Cmos Sensor 20m IR Outdoor 960P 1.3MP AHD Camera photo-1

1/3 Cmos Sensor 20m IR Outdoor 960P 1.3MP AHD Camera photo-2

1/3 Cmos Sensor 20m IR Outdoor 960P 1.3MP AHD Camera photo-3

1/3 Cmos Sensor 20m IR Outdoor 960P 1.3MP AHD Camera photo-4

1/3 Cmos Sensor 20m IR Outdoor 960P 1.3MP AHD Camera photo-5

1/3 Cmos Sensor 20m IR Outdoor 960P 1.3MP AHD Camera photo-6

US$ 13.9 - 19.9 MOQ: 1 Unit

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

ISEC or OEM

Model Number:

IC-LDW20-B

Contact Supplier Request Quote Chat Now

Shenzhen Isec Technologies Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name ISEC or OEM

Model Number IC-LDW20-B

Type Digital Camera

Style Dome Camera

Sensor Other, CMOS, 1/3" OV CMOS

Technology Infrared

Special Features Waterproof / Weatherproof

Product Description

ISEC do your Security Backing, Taking Care Of your loved ones wherever you are...

1/3 Cmos Sensor 20m IR Outdoor 960P 1.3MP AHD Camera

Feature:

1, 1/3 Cmos Sensor 20m IR Outdoor 960P 1.3MP AHD Camera

2, Up to 500meters Transmission Distance by Coaxial Cable, extended cable

3, 1/3" 1/4" Cmos Image Sensor, 1080P 720P and 960P Optional, Osd Menu controlled by cable

4, 24(f 0.5) LED IR illuminators view up to 20meters night vision

5, 3.6mm 3MP Fixed len, DC12V Power supply , Easy to install

6, Analog High Definition Camera, CE/FCC/RoHS.

What is AHD Camera?

What is Image Effect Of AHD Camera?

What are features of ISEC AHD Camera?

What is Specification of ISEC AHD Camera?

Model NO.	IC-LDW20-BA7	IC-LDW20-BA7B	IC-LDW20-BA7C	IC-LDW20-BA7D
VIDEO
Image Device	1/4" 1MP OV9712 CMOS	1/3" 1.3MP IMX238 CMOS	1/4" 1MP AR0141A CMOS	1/3" 1.3MP AR0130 CMOS
DSP	NVP2431
TV System	PAL/NTSC
Effective Pixels	1280(H)×720(V) , 1MP	1280(H)*960(V) 1.3MP	1280(H)×720(V) , 1MP	1280(H)*960(V) 1.3MP
Scanning System	Progressive Scan
Synchronization	Internal
Image Resolution	1280*720(720P)	1280*960(960P)	1280*720(720P)	1280*960(960P)
Frame rate	PAL: 25fps(at)720P(1280×720); NTSC: 30fps(at)720P(1280×720)
Min. Illumination	Color: 1.0lux(at)F1.2; B/W: 0 Lux(IR ON)
S/N Ratio	>50dB
Video Output	AHD/CVBS (960H)
LENS
Focal Length	3.6mm lens 2.8/6mm lens option
IR-CUT	3MP IR filter cut
OPERATIONAL(OSD MENU)
Day & Night	AUTO /COLOR /B/W /EXT
D-WDR	OFF/ON/AUTO
Noise Reduction	3DNR: OFF/Low / Middle / High
Back Light	BLC/HSBLC/OFF
Auto Gain Control	0~15 Adjustable
Defog	OFF / AUTO
Motion Dectection	ON(Motion area and sensitivity can be settled)/OFF
Sense Up	OFF/AUTO(2X~30X Adjustable)
Pricacy Mask	OFF/ON(8 Masks)
Electronic Shutter Speed	2X~30X/AUTO/1/50 ~ 1/50,000sec
White Balance	ATW/AWC→SET/INDOOR/OUTDOOR/MANUAL/AWB
Brightness	0~100 Adjustable
Mirror	OFF/MIRROR/V-FLIP/ROTATE
Sharpness	OFF/AUTO(Level,Start AGC and End AGC can be settled)
OSD Language	English, Chinese, Spanish, German, French, Russian, Portuguese, Italian, Polska, Nederland, Turkish
General
Infrared LED	24pcs Ø5mm IR LEDs
IR Distance	about 20 Meters
Infrared Spectrum	850nm
Input Current	400mA
Adapter Requirement	DC 12V, 1A
Water-proof	IP66
MECHANICAL
Color	White case
Bracket	/
Dimensions	Ø92X76(H)mm
Net Weight	0.4kg/pcs
ENVIRONMENTAL
Operation Temperature	-10℃~ +50℃
Storage Temperature	-20℃~ +60℃

How to connect AHD Camera DVR?

Where does ISEC AHD Camera use?

Packaging & Shipping

Packaging & Shipping:

Our Services

Why Choose Us?

♦ We are Alibaba Assessed 6 years Gold Supplier.

♦ We are a factory manufacturing Cctv Cameras, Withmore than 9 Years experience.

♦ Strictly Quality Control: More than 12 hours aging before sending,Ce,Fcc,Rohs.

♦ Competitive Price: Factory price (EXW), Big discount for bulk order.

♦ Technical support: Provide all-around technical support and counselling all the time.

Our Security Equipment:

Customers Feedback:

Factory View:

Our Certifications:

Factory Activities:

FAQ

FAQ:

Q1: What is the Warranty for the camera?

A1: For the cameras,we have 2 years warranty.If any quality problems on our side occured in this period ,free repair or replace units are available.

Q2: What is the estimate delivery time?

A2: Factory usually need 3-4 working days to prepare sample order, around 5-7 working days for bulk order .

Q3: What is your payment term?

A3: We accept T/T, Western Union, Paypal, Escrow, L/C at present .

Q4: Do you offer Oem service?

A4: Oem service is available in our factory, Could you tell us which is suitable for you please: special design,customize specification, logo silk print or customize retail boxes?
